Vol 68, No 4 (2023)
К 90-ЛЕТИЮ ВЛАДИМИРА ГРИГОРЬЕВИЧА ШАВРОВА
Magnetocaloric Materials for Low-Temperature Magnetic Cooling
Abstract
State of research in the study of magnetocaloric materials based on rare-earth metals that are promising for application in the technology of low-temperature magnetic cooling is reviewed. Physical principles and characteristics of the magnetocaloric effect in materials based on rare-earth metals with low-temperature magnetic phase transitions are presented.
On the Possible Half-Metallic Properties of Fe2RhZ (Z = Al, Si, Ga, Ge, In, Sn) Ferromagnetic Heusler Alloys
Abstract
The possible presence of half-metallic properties in Fe2RhZ (Z = Al, Si, Ga, Ge, In, Sn) ferromagnetic Heusler alloys is ab initio studied. The calculation is carried out taking into account the exchange correlation effects using the generalized and meta-generalized gradient approximations. It is shown that the ground state of most investigated alloys is ferromagnetic ordering in the Тр model lattice. An analysis of the phase stability of the alloys showed that, in the considered approximations, most of them are stable in both the regular and inverse lattice, as well as in the three model lattices belonging to inverse-type Heusler structures with different atomic orders. It was predicted using the strongly constrained and appropriately normed (SCAN) functional that the Fe2RhSi alloy can exhibit the properties of half-metals, since it has an integer magnetic moment, a fairly high degree of polarization, and an energy gap at the Fermi level of spinup electrons.
Functionalities of Ni–Ti Shape Memory Alloys and Their Efficiency as Event Actuators of Microelectromechanical Systems
Abstract
The functionalities of Ni–Ti alloys subjected to different deformation treatments are studied. A critical stress corresponding to the onset of degradation of the functional properties were determined; it was found that this stress is about twice as low as the yield stress. The efficiency coefficients of virtual thermodynamic machines with a working body made of the investigated materials were calculated and compared with the efficiency of a Carnot engine based on the same materials; the ideality factor has been calculated under the condition of actuating at stresses no higher than critical ones. It has been established that, at the single actuation, the highest ideality factor (9.7%) is characteristic of a material consisting of bars 20 to 5 mm in diameter obtained by warm forging at 350°C. It has been determined that, at discontinuous operation under stresses lower than the critical ones by a factor of 1.2, the ideality factor is 7.4–7.7% for alloys subjected to hot forging or equal channel angular pressing combined with warm forging.
Magnetocaloric Effect in a Ni2.25Mn0.75Ga0.93Si0.07 Alloy
Abstract
The results of a study of the magnetocaloric effect (MCE) in Ni2.25Mn0.75Ga0.93Si0.07 alloy are presented in the cast state and in the state after multi-axial isothermal forging (MIF) at 700°C and true degree of deformation e = 3.19. It is shown that as a result of MIF, the initial equiaxed microstructure is transformed into a bimodal one in which large grains 100–200 μm in size are surrounded by a layer of fine-grained microstructure.
As a result of MIF, the range of martensitic transformation is slightly shifted to the region of low temperatures by about 5°C. The analysis of phase transformations in the region of room temperatures shows that the intervals of martensitic and magnetic phase transformations are superimposed on each other. The MCE value in a magnetic field of 1.8 T is 0.59ºC in the initial cast state, and as a result of forging it decreases to 0.55°C.
Inverse Magnetocaloric Effect in Mn5Si3 Compound
Abstract
A direct method was used to study the magnetocaloric effect (MCE) for samples of the compound Mn5Si3 under adiabatic conditions in magnetic fields up to 2 T at cryogenic temperatures in the range from 25 to 125 K. According to the results of measurements, it is shown that at temperatures near the first-order metamagnetostructural phase transition from a noncollinear antiferromagnetic to a collinear antiferromagnetic state, both inverse and сonventional MCE are observed. The maximum value of the inverse MCE was ΔTad = –0.27 K at initial temperature T0 = 55 K in a magnetic field of 2 T. Conventional MCE with maximum value ΔTad = +0.23 K is observed at T0 = 70 K in a field of 2 T.
Thermal Contact Resistance at Cryogenic Temperatures in the Presence of Strong Magnetic Fields
Abstract
A physical model of a mechanical thermal switch at cryogenic temperatures is studied. In the model, heat is transferred due to contact heat conduction in a detachable contact pair of two copper cylinders. A mechanical thermal switch is developed using a cryomagnetic system with a 10-T superconducting solenoid, and the values of thermal contact conductance are determined in a temperature interval of 10–160 K, including values at a magnetic field of 5 T. In an experimental temperature interval of 60–80 K, close to the phase transition of the DyAl2 and GdNi2 compounds, the thermal contact conductance is 2300–3300 W/(m2 K). The effect of magnetic field of up to 5 T on thermal contact resistance is experimentally determined under vacuum conditions
RNi (R = Gd and Dy) Compound-Based Magnetocaloric Materials
Abstract
High-performance materials for solid-state magnetic cooling in the temperature range of 1.5–100 K were developed. The magnetic and magnetocaloric properties of the new (R, R')Ni (R = Gd and R' = Dy) compounds and their hydrides were studied in the Curie temperature region. The main regularities in the behavior of the temperature dependences of the magnetocaloric effect for different compositions were established.
Magnetic and Magnetocaloric Characteristics of the Mn1.9Cu0.1Sb Alloy
Abstract
The magnetic and magnetocaloric characteristics of the Mn1.9Cu0.1Sb alloy were studied. The presence of a relatively sharp decrease in the magnetization in the region of 100 K is established, which, according to ab initio calculations, can be interpreted as antiferromagnetism–ferrimagnetism transitions. The presence of a magnetic phase transition from a ferrimagnetic to an antiferromagnetic state (F ↔ AF) leads to the appearance of an inverse magnetocaloric effect, which is preserved in magnetic fields up to 10 T.
Electronic Structure and Properties of the Ground State of Fe–Pt Based Alloys
Abstract
The properties of the ground state and the electronic structure of Fe2PtZ (Z = Ga, In, Ge, Si, Sn, Al) and FeRh1 – xPtx in the framework of the density functional theory implemented in the VASP software package alloys have been studied. Densities of electronic states for Fe2PtZ and FePt are obtained. It is shown that in Fe2PtIn and FePt high values of spin polarization are observed. It has been found that with increasing platinum concentration, the staggered antiferromagnetic spin configuration becomes unstable, and in the concentration range above 0.625, the antiferromagnetic configuration with layer-by-layer alternation of magnetic moment directions becomes advantageous. It was found that with a further increase in the platinum concentration, a ferromagnetic phase is observed.
Magnetocaloric Effect in the Laves Phase of GdNi2 in Strong Magnetic Fields
Abstract
Experimental studies of the magnetic and magnetocaloric properties of the Laves phase of GdNi2 have been carried out in external static up to 3 T and pulsed up to 50 T magnetic fields. It has been found that in a magnetic field of 3 T the change in the magnetic entropy of the alloy reaches its maximum value ΔSm = −8 J/(kg K) in the vicinity of the Curie temperature TC = 73.6 K. The corresponding adiabatic temperature change in this case, calculated by an indirect method, is ΔTad ≈ 3 K. The maximum value of the adiabatic temperature change measured by the direct method in a pulsed magnetic field of 50 T at T0 = 77 K, was equal to ΔTad = 15 K, which agrees well with theoretical predictions.
Magneto-Optical Visualization of Magnetic Phases in an Epitaxial Film of Ferrite–Garnet Near the Compensation Point
Abstract
A method for the magneto-optical visualization of magnetic phases in ferrimagnets in the vicinity of the compensation point in the lateral temperature gradient is described. On the example of films of bismuth–gadolinium ferrite garnet, zones corresponding to collinear and non-collinear magnetic phases were observed, depending on the temperature and the magnitude of the magnetic field in the range from 0 to 10 T.
Application of Heat Treatment to Optimize the Magnetostrictive
Abstract
The heat treatment effect of the magnetostrictive component in magnetoelectric (ME) composites consisting of a piezoelectric and magnetostrictive material has been studied. The dependence of the ME voltage coefficient on frequency was experimentally found without heat treatment and with annealing from 200 to 500°C of the AMAG493 amorphous alloy, which acted as a magnetostrictive component. It is shown that with an increase in the processing temperature of an amorphous alloy, an increase in the ME voltage coefficient is observed: the maximum value of the ME coefficient was observed at a temperature of 350°C and amounted to 29.52 V cm–1 Oe–1 at a resonance frequency of 54 kHz. It has been proven that the increase in the ME voltage coefficient occurs due to the improvement in the characteristics of the amorphous alloy during heat treatment, which leads to partial nanocrystallization of the material.
ПРИМЕНЕНИЕ РАДИОТЕХНИКИ И ЭЛЕКТРОНИКИ В БИОЛОГИИ И МЕДИЦИНЕ
Prospects for Infrared Luminescent Diagnostics of Superficially
Abstract
In this paper, we developed a promising technique for luminescent infrared (IR) diagnostics of neoplasms of visually and endoscopically accessible localization (dermatology, gynecology, dentistry) using ytterbium complexes of porphyrins. Possible mechanisms of accumulation of a pharmaceutical composition based on the ytterbium complex of 2,4-di(α-methoxyethyl)deuteroporphyrin IX (Yb-DMDP) in tumor tissues were studied. Studies on the pharmacokinetics and biodistribution of this substance in various organs and neoplasms of laboratory animals showed a significant selectivity of the accumulation of nanoparticles with ytterbium ions in tumors as early as 24 h after intravenous administration. For the purposes of luminescent IR diagnostics, a highly sensitive laser-fiber fluorimeter operating in the spectral range of 900–1100 nm was developed. Preclinical tests of the developed method of fluorescent IR cancer diagnostics were carried out and its prospects were shown.
