Surface Morphology and Photoluminescence Spectra of Pseudomorphic {InGaAs/GaAs} Superlattices on GaAs (100), (110), and (111)A Substrates

Authors: Klimov E.A.¹^,2, Pushkarev S.S.¹, Klochkov A.N.³, Mozhaeva M.O.²
Affiliations:
1. Mokerov Institute of Ultra High Frequency Semiconductor Electronics, Russian Academy of Sciences
2. State Scientific Center of the Russian Federation Joint Stock Company NPO “Orion,”
3. National Research Nuclear University “MEPhI,”
Issue: Vol 52, No 3 (2023)
Pages: 167-173
Section: ДИАГНОСТИКА
URL: https://journals.rcsi.science/0544-1269/article/view/138550
DOI: https://doi.org/10.31857/S054412692370031X
EDN: https://elibrary.ru/UDRWAA
ID: 138550

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The production of superlattices with pseudomorphically strained quantum wells (QWs) {InxGa1–xAs/GaAs} grown by molecular beam epitaxy on GaAs substrates with (100), (110), and (111)A crys-tallographic surface orientations is reported. The quality of the crystal structure of epitaxial samples is assessed using the atomic force microscopy of their surface. The manifestation of a piezoelectric field in the photoluminescence spectra is reported.
