Vol 68, No 6 (2023)
К 85-ЛЕТИЮ ДМИТРИЯ СЕРГЕЕВИЧА ЛУКИНА
Investigation and Methods for Solving Problems of Scattering of Electromagnetic Waves on Three-Dimensional Anisotropic Dielectric Structures
Abstract
The problems of scattering of electromagnetic waves by anisotropic dielectric structures are studied on the basis of volumetric singular integral equations. Existence and uniqueness theorems for solutions are given for a wide class of media, including lossless media. An efficient method for solving integral equations based on the collocation method and fast discrete Fourier transform algorithms is described.
Asymptotics of the Localized Bessel Beams and Lagrangian Manifolds
Abstract
The Bessel beam-type asymptotic solutions of the three-dimensional Helmholtz equation, i.e., the solutions that have maxima in the vicinity of the -axis and are described by Bessel functions in the planes normal to it, are discussed. Since the Bessel functions slowly decrease at infinity, the energy of such solutions appears unlimited. Approaches to localizing such solutions by representing them in the form of the Maslov canonical operator on proper Lagrangian manifolds with simple caustics in the form of degenerate and nondegenerate folds are described. Efficient formulas for these solutions in the form of Bessel and Airy functions of a complex argument are obtained.
Fresnel-Type Transition Zones
Abstract
A family of exact solutions of the two-dimensional Helmholtz equation is constructed, which are suitable for describing wavefields in transition zones arising in Fresnel-type diffraction. As examples, in addition to wedge diffraction, high-frequency asymptotics of the field in problems of diffraction on obstacles with non-smooth curvature are considered.
Mathematical Modeling of the Amplitude, Angular, and Time Characteristics of Short Radio Waves in Slightly Oblique Sounding of the Ionosphere
Abstract
The method of bicharacteristics is used to study the propagation of decameter radio waves in the ionosphere containing the E, F1, and F2 layers and a traveling ionospheric disturbance (TID) upon slightly oblique sounding with frequency-modulated signals. The propagation of both ordinary and extraordinary waves is considered, the ionograms are compared, and their relative shift is studied. The structure of ionograms in the vicinity of caustics, which appear at the reception point at frequencies reflected in the vicinity of the E layer and TID, is studied. The divergence of the ray flux at the point of radiation reception, which determines a decrease in the amplitude, is calculated.
Diffraction Theory of Propagation of High-Frequency Radio Waves in a Spherically Layered Ionospheric Radio Channel
Abstract
A special analytical method is developed to describe the propagation of high-frequency electromagnetic waves emitted by a vertical point dipole from the surface of perfectly conducting Earth in a regular spherically layered background ionosphere. The basic representation of the wave field employs an integral over the set of wave components, each of which is related to a specific ray trajectory. Such an approach makes it possible to analytically take into account the effect of medium-scale 3D inclusions in the background ionosphere as an additional phase shift of the wave component with allowance for the distortion of its ray trajectory and to numerically calculate the effect of wave-field focusing.
Implementation of the Maximum Bandwidth Ratio of Satellite Radio Communication Systems under the Conditions for Intramodal Dispersion of Transionospheric Radio Channels
Abstract
The problem of significant extension of the band of the transionospheric radio channel to the maximum possible values is solved to improve the efficiency of satellite communication systems. Hardware and software are created to suppress the group delay dispersion using methods of data mining for experimental diagnostics of a transionospheric communication line. Algorithms and tools for intelligent sensory diagnostics of wideband radio channels with adaptation to dispersion variability are developed. In the absence of adaptation, it is possible to create radio channels of undistorted transmission with a bandwidth ratio of no greater than 4.5%, while adaptation to dispersion variability makes it possible to increase the bandwidth ratio to 11.5%. The greatest bandwidth ratio (20–25%) for dispersion-free transmission can be achieved with the aid of adaptive inverse filtering of the channel frequency response in combination with such intelligent methods as equalization with error, machine learning of channel equalizer, and big data processing.
Multibeam Antenna with a Full Azimuth Field Angle Based on a Layered Metal-Dielectric Cylindrical Lens
Abstract
A multibeam antenna based on a layered lens with axial symmetry in the form of a set of dielectric disks with a refractive index gradient along the radius, which are located between metal disks, is proposed and investigated. A layered lens converts the fields of feeds located on a circle centered on the axis of the lens in the plane of its base into highly directed beams in the same plane. A synthesis of a layered lens is carried out, the layers of which are made in the form of a set of dielectric rings of variable thickness. The analysis of a multibeam lens antenna with metal-dielectric feeds was carried out by numerical simulation using the finite element method.
Signal Receiver for Global Navigation Satellite Systems Based on a U-Blox ZED-F9P Module for Ionospheric Research
Abstract
The results of the development of a prototype of the receiver of signals from global navigation satellite systems (GNSS) based on the U-blox ZED-F9P module are presented and a comparative analysis of its characteristics with professional GNSS receivers Trimble Alloy (KZN2 station of the IGS network) and JAVAD TRE-3L in the registration problem is performed. A qualitatively and quantitatively comparable behavior of the studied parameters for all types of GNSS receivers is noted.
Microwave Radiometric System in Problems of Forecasting Hazardous Atmospheric Phenomena
Abstract
The main directions of improving radiometric microwave systems for solving problems of ultrashort-term forecasting of the development of adverse and dangerous atmospheric weather phenomena are shown, which consist in solving problems of compensating for the influence of background noise, digital processing of output signals, and including radio-photonic paths and a neural network in the system. The results of correlation processing of data from remote sensing of the surface layer of an inhomogeneous atmosphere in three frequency ranges are presented.
Estimation of Probabilistic Characteristics of Reception of Frequency-Effective Signals during Propagation along a Radio Line with Fog
Abstract
A model of a radio line with fog, which is used to represent distortions of complex envelopes of digital signals because of the absorbing and dispersive properties of the propagation medium, has been considered. It is shown that with an increase in the frequency band of digital signals and with an increase in their order of manipulation (when using frequency-efficient signals), the influence of these distortions leads to energy losses in relation to propagation in free space. The quantitative estimation of energy losses for the digital signals used in applications with multi-position phase, quadrature-amplitude, and amplitude-phase manipulations and for a radio line with fog with a variation of its parameters has been carried out. It has been shown that for signals with multiposition phase and amplitude-phase manipulations (the frequency efficiency coefficient of the signals is 4 bits/s/Hz), the energy losses reach 3.5 and 1.0 dB, respectively.
Study of Ultra-High Frequency Radiometric Humidity Sounding of the Atmosphere for the Early Warning of Hazardous Weather Phenomena
Abstract
Ground-based microwave radiometry was used to study the characteristics of the moisture content of the atmosphere during the development of cloud-related hazardous weather phenomena, precipitation, and thunderstorms. On the basis of complex radiophysical studies of the atmosphere, carried out in the Leningrad oblast, the possibility of improving the methods of early warning of dangerous weather phenomena and diagnostics Ground-based microwave radiometry was used to study the characteristics of the moisture content of the atmosphere during the development of cloud-related hazardous weather phenomena, precipitation, and thunderstorms. On the basis of complex radiophysical studies of the atmosphere, carried out in the Leningrad oblast, the possibility of improving the methods of early warning of dangerous weather phenomena and diagnostics of atmospheric fronts with the involvement of operational microwave radiometric information is shown.
Spectral Parameters of Signal in a Meteorological Radar
Abstract
Specific features of the application of the spectral parameters of the received signal for the recognition of dangerous weather phenomena in a meteorological radar are considered. The advantages and disadvantages of existing methods are outlined. A new recognition method based on the estimation of the base of the input random process is proposed.
