Characterization of vertically aligned carbon nanotubes by piezoresponse force microscopy

M. V. Il’ina; Ильина М. В.; O. I. Soboleva; Соболева О. И.; M. R. Polyvianova; Полывянова М. Р.; D. I. Selivanova; Селиванова Д. И.; S. A. Khubezhov; Хубежов С. А.; O. I. Il’in; Ильин О. И.

doi:10.31857/S0367676523702447

Characterization of vertically aligned carbon nanotubes by piezoresponse force microscopy

作者: Il’ina M.¹, Soboleva O.², Polyvianova M.², Selivanova D.², Khubezhov S.²^,3, Il’in O.²
隶属关系:
1. Southern Federal University, Institute of Nanotechnologies, Electronics and Equipment Engineering
2. Southern Federal University, Research Laboratory of Functional Nanomaterials Technology
3. North Ossetian State University
期: 卷 87, 编号 10 (2023)
页面: 1397-1403
栏目: Articles
URL: https://journals.rcsi.science/0367-6765/article/view/141833
DOI: https://doi.org/10.31857/S0367676523702447
EDN: https://elibrary.ru/GXAYJJ
ID: 141833

如何引用文章

全文:

开放存取

##reader.subscriptionAccessGranted##
受限制的访问

订阅存取

详细
作者简介
参考
补充文件
统计

详细

The piezoelectric properties of vertically aligned carbon nanotubes (CNTs) are characterized using the piezoresponse force microscopy method. Dependence of piezoelectric properties on the nitrogen concentration is established. It is shown that CNTs have predominantly longitudinal polarization due to the direction of the dipole moment in the bamboo-like “bridges”. It has been established that a decrease in the growth temperature from 690 to 645°С leads to an increase in the piezoelectric strain coefficient of CNTs from 4.5 to 21.2 pm ⋅ V^–1. The obtained results can be used in the development of energy-efficient nanopiezotronic devices.

参考

Wang Z.L. // Adv. Mater. 2012. V. 24. No. 34. P. 4632.
Wang Z.L. // Adv. Mater. 2007. V. 19. No. 6. P. 889.
Gao Y., Wang Z.L. // Nano Lett. 2007. V. 7. No. 8. P. 2499.
Hu Y., Wang Z.L. // Nano Energy. 2014. V. 14. P. 3.
Wang Z.L. // Nano Today. 2010. V. 5. No. 6. P. 540.
He J. H., Hsin C. L., Liu J. et al. // Adv. Mater. 2007. V. 19. No. 6. P. 781.
Mahapatra S. Das, Mohapatra P.C., Aria A.I. et al. // Adv. Sci. 2021. V. 8. No. 17. Art. No. 2100864.
Choi I., Lee S.-J., Kim J.C. et al. // Appl. Surf. Sci. 2020. V. 511. Art. No. 145614.
Wang X., Tian H., Xie W. et al. // NPG Asia Mater. 2015. V. 7. No. 1. Art. No. e154.
da Cunha Rodrigues G., Zelenovskiy P., Romanyuk K. et al. // Nature Commun. 2015. V. 6. Art. No. 7572.
Bistoni O., Barone P., Cappelluti E. et al. // 2D Mater. 2019. V. 6. No. 4. Art. No. 045015.
Duggen L., Willatzen M., Wang Z.L. // J. Phys. Chem. C. 2018. V. 122. No. 36. P. 20581.
Chandratre S., Sharma P. // Appl. Phys. Lett. 2012. V. 100. No. 2. Art. No. 023114.
Ong M.T., Reed E.J. // ACS Nano 2012. V. 6. No. 2. P. 1387.
Il’ina M.V., Il’in O.I., Guryanov A.V. et al. // J. Mater. Chem. C. 2021. V. 9. No. 18. P. 6014.
Il’ina M., Il’in O., Osotova O. et al. // Carbon. 2022. V. 190. P. 348.
Il’ina M.V., Osotova O.I., Rudyk N.N. et al. // Diam. Relat. Mater. 2022. V. 126. Art. No. 109069.
Il’ina M.V., Soboleva O.I., Rudyk N.N. et al. // J. Adv. Dielectr. 2022. Art. No. 2241001.
Il’ina M.V., Il’in O.I., Smirnov V.A. et al. Atomic-force microscopy and its applications. IntechOpen, 2019. P. 49.
Агеев О.А., Ильин О.И., Коломийцев А.С. и др. // Нано-микросист. техн. 2012. № 3. С. 9.
Il’ina M. V., Il’in O.I., Rudyk N.N. et al. // Nanomaterials. 2021. V. 11. No. 11. Art. No. 2912.
Il’in O.I., Il’ina M.V., Rudyk N.N. et al. // Nanosyst. Phys. Chem. Math. 2018. V. 9. No. 1. P. 92.
Neumayer S.M., Saremi S., Martin L.W. et al. // J. Appl. Phys. 2020. V. 128. No. 17. Art. No. 171105.
Il’in O.I., Rudyk N.N., Fedotov A.A. et al. // Nanomaterials. 2020. V. 10. No. 3. Art. No. 554.
Louchev O.A. // Phys. Stat. Sol. Appl. Res. 2002. V. 193. No. 3. P. 585.
Lee W.J., Maiti U.N., Lee J.M. et al. // Chem. Commun. 2014. V. 50. No. 52. P. 6818.
Yamada Y., Kim J., Matsuo S., Sato S. // Carbon. 2014. V. 70. P. 59.
Inagaki M., Toyoda M., Soneda Y., Morishita T. // Carbon. 2018. V. 132. P. 104.
Arenal R., Henrard L., Roiban L. et al. // Nano Lett. 2014. V. 14. No. 10. P. 5509.
Kundalwal S.I., Meguid S.A., Weng G.J. // Carbon. 2017. V. 117. P. 462.
Ильина М. В., Ильин О. И., Осотова О. И. и др. // Росс. нанотехнол. 2021. Т. 16. № 6. С. 857. Il’ina M.V., Il’in O.I., Osotova O.I. et al. // Nanobiotechnol. Rep. 2021. V. 16. No. 6. P. 821.
Il’ina M.V., Il’in O.I., Osotova O.I. et al. // Diam. Relat. Mater. 2022. V. 123. Art. No. 108858.
