卷 69, 编号 5 (2023)

The results of studies of the features of the formation of pulse characteristics on the axis of an underwater sound channel in waveguides with different hydrological and bathymetric conditions of the Sea of Japan and the Sea of Okhotsk are discussed. The results of model calculations and experiments characterizing the regularities of propagation of low-frequency pulse signals in complex waveguides including shelf and deep sea for hundreds of kilometers are presented. It is shown that one of the main effects that determines long-range sound propagation in complex waveguides including the shelf and deep sea is the acoustic “landslide” effect. It is also shown that numerical modeling of the process of signal propagation from the shelf to the deep sea on acoustic traces in the Sea of Japan and the Sea of Okhotsk using the RAY program provides good convergence of the calculated and experimentally obtained impulse characteristics.

A method and algorithm for remote detection of sound-scattering layers in the seas and oceans using strip survey data of the bottom topography by interferometric side-scan sonar (ISSS) is considered. Based on mathematical modeling of phase-difference measurements of ISSS for multilayer scattering planes in seawater, we demonstrate the possibility of detecting sound-scattering layers and measuring their depths using the proposed algorithm. The accuracy of calculating the depths of sound-dispersing layers at a constant value of the sound velocity has been evaluated and the requirements to the ISSS have been determined to ensure the necessary accuracy of detection of individual layers located at different depths. The efficiency of the proposed method is demonstrated based on the example of processing by the developed algorithm of the experimental data obtained during bottom relief studies with an 85 kHz range ISSS.

The purpose of this paper is to numerically demonstrate and comparatively analyze the critically strong and ambiguous impact of the a priori uncertainty of a shallow sea waveguide model in its main physical parameters on the output performance of model-based methods for spatial processing of multimode signals received by a vertical antenna array. The scenario is specified when a relatively weak signal of a remote underwater source is received against the background of intensive interference excited by a subsurface source (like a ship, for example) and ambient sea noise excited by wind waves. The considered array processing methods include matched-signal processing, optimal processing of the signal on the background of interference and noise, and suboptimal processing based on matched-mode array filtering of one of the signal-carrying modes with adaptive selection of its number. Quantitative estimates are obtained from above for the environment uncertainties, or model errors, with respect to the sound velocity in the water column and geoacoustic parameters of the underlying bottom, at which the array gain loss does not exceed a given level. It is shown that such estimates are very different both for different environmental parameters and for processing methods, with the determining role played by the conditions of useful signal reception, namely, the modal composition and intensity levels of the interference and sea noise at the array input. The problem statement and results are considered to be useful to detail the requirements for operational oceanography tools designed to support the effective operation of sonar antenna systems in real sea environments.

In experiments on a stationary acoustic track under a solid ice cover, estimates of possible sound signal propagation time variations at distances of ∼4 km with a period of more than 100 s were obtained. The experiments were carried out on Lake Baikal in the spring period, when the vertical profile of the sound speed has two sections characteristic of freshwater areas: an upper layer with a near constant sound speed and a lower layer with linear growth of sound speed. Under these conditions, the variations of the propagation time did not exceed ~10–4 s. Numerical modeling showed that the variations of propagation times due to the variability of the medium are minimal for the case when the sound source and receiver are located in the upper layer. It is demonstrated that in this case it is acceptable to take the sound speed in the upper quasi-homogeneous layer as the effective value of the sound speed, which determines the propagation time. The obtained results allowed us to formulate recommendations on under-ice acoustic positioning of autonomous underwater vehicles.

The effect of random internal waves on the gain and pattern of a horizontal antenna array in a shallow sea has been investigated. An algorithm for calculating the correlation matrix of the point source field at the grating aperture is proposed. The antenna gain is analyzed for different spatial processing methods: the beam forming method, the optimal linear processing method, and the optimal quadratic processing method. The effect of internal waves on the directivity pattern is described by the dispersion of the angular response of the grating. Numerical simulation results are presented for a model summer-type waveguide and an exponential Brunt–Väisälä frequency profile. The empirical internal wave spectrum proposed earlier from the SWARM95 experiment is used. The dependences of the antenna array characteristics on the number of its elements, orientation with respect to the source, radiation frequency, and the acoustic characteristics of the bottom are analyzed.

A broadband (35–1000 Hz) sound field formed by a point source in a shelf zone with inhomogeneous bottom sediment structure is studied using numerical modeling. The shelf depth is about 30 m and the maximum distance is 10 km. The transitional zone from the bottom with a sound speed of 1400 m/s to the bottom with a speed of 1600 m/s is chosen as the model inhomogeneity. The normal mode theory and wide-angle parabolic equations are used for sound field calculations. Numerical experiments show that the manifestation of horizontal refraction is noticeable at low frequencies (below 100 Hz). It leads to an increase in the amplitude of the low-frequency sound pulse propagating along the transitional zone by more than 10 dB in comparison with a similar waveguide with a homogeneous bottom. At frequencies above 100 Hz, the dominant effect is the mode coupling, causing the appearance of quasi-periodic oscillations of modal amplitude in the frequency domain. The conclusions from the simplified model are confirmed by calculations for the real structure of bottom sediments in the Kara Sea.

A method for estimating ocean ice cover parameters (thickness, Young’s modulus, Poisson ratio, and density) that does not require the use of a source is proposed and tested on experimental data. To realize the approach, two single-channel seismic receivers located on the ice surface are required to record the vertical component of the oscillatory velocity of the seismic noise. The spectral-correlation analysis of the mutual correlation function of the noise registered by the receivers allows us to estimate the dispersion dependence of the group velocity of the bending-gravity wave propagating along the ice plate. The solution of the inverse problem is based on analyzing the variance of not only the group but also the phase velocity, which allows us to increase the amount of primary data. The obtained estimates of ice parameters are consistent with the results of independent observations carried out during the experiment, as well as with the estimates of other authors obtained for ice characteristics in the region of the experiment.
