Plasma Spraying of Silicide Coatings to Protect Zirconium Alloys from Oxidation

I. B. Gnesin; Гнесин И. Б.; D. V. Prokhorov; Прохоров Д. В.; N. I. Gnesina; Гнесина Н. И.; A. N. Nekrasov; Некрасов А. Н.; B. A. Gnesin; Гнесин Б. А.; V. I. Vnukov; Внуков В. И.; M. I. Karpov; Карпов М. И.; I. S. Zheltyakova; Желтякова И. С.; T. S. Stroganova; Строганова Т. С.

doi:10.31857/S1028096023100059

Plasma Spraying of Silicide Coatings to Protect Zirconium Alloys from Oxidation

Authors: Gnesin I.B.¹, Prokhorov D.V.¹, Gnesina N.I.¹, Nekrasov A.N.², Gnesin B.A.¹, Vnukov V.I.¹, Karpov M.I.¹, Zheltyakova I.S.¹, Stroganova T.S.¹
Affiliations:
1. Institute of Solid State Physics RAS
2. Institute of Experimental Mineralogy RAS
Issue: No 10 (2023)
Pages: 27-35
Section: Articles
URL: https://journals.rcsi.science/1028-0960/article/view/141023
DOI: https://doi.org/10.31857/S1028096023100059
EDN: https://elibrary.ru/VZYMAM
ID: 141023

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The work is devoted to an experimental study of the possibilities of applying a protective silicide coating on an alloy based on zirconium (E110) by atmospheric plasma spraying. Coatings based on the binary eutectic Mo₅Si₃ + MoSi₂ were deposited on the surface of E110 alloy sheet. The features of the structure and phase composition of the coatings after deposition and their evolution as a result of isothermal annealing at a temperature of 1300°C are studied. Upon rapid cooling of silicide particles during coating, nonequilibrium phases are formed. As a result of annealing, the phase composition changes, which corresponds to the phase diagram. The kinetics of diffusion interaction between the coating and the base material has been studied. The possibility of successfully protecting a zirconium alloy from oxidation at 1100°C in air by complex deposition of a coating of molybdenum silicides has been shown for the first time. The minimum radius of curvature of the surface of the protected samples was about 1 mm.

Keywords

protective coatings, molybdenum silicides, protection against oxidation, thermogravimetry, zirconium, vapor-zirconium reaction, tolerant fuel, phase composition, microstructure, scanning electron microscopy.

References

Разработка, производство эксплуатация тепловыделяющих элементов энергетических реакторов. Кн. 1. / Ред. Решетников Ф.Г. М.: Энергоатомиздат, 1995. 320 с.
The Fukushima Daiichi Accident. Vienna. IAEA, 2015. 1254 p.
Corey G.R // IAEA Bull. 1979. V. 21. № 5. P. 54.
Accident Tolerant Fuel Concepts for Light Water Reactors. Vienna. IAEA-TECDOC-1797, 2016. 384 p.
Maier B., Yeom H., Johnson G., Dabney T., Walters J., Romero J., Shah H., Xu P., Sridharan K. // JOM. 2018. V. 70. P. 198. https://doi.org/10.1007/s11837-017-2643-9
Gigax J.G., Kennas M., Kim H., Maier B.R., Yeom H., Johnson G.O., Sridharan K., Shao L. // J. Nucl. Mater. 2019. V. 519. P. 57. https://doi.org/10.1016/j.jnucmat.2019.03.004
Dabney T., Johnson G., Yeom H., Maier B., Walters J., Sridharan K. // Nucl. Mater. Energy. 2019. V. 21. 100715. https://doi.org/10.1016/j.nme.2019.100715
Maier B.R., Garcia-Diaz B.L., Hauch B., Olson L.C., Sindelar R.L., Sridharan K. // J. Nucl. Mater. 2015. V. 466. P. 712. https://doi.org/10.1016/j.jnucmat.2015.06.028
Yeom H., Hauch B., Cao G., Garcia-Diaz B., Martinez-Rodriguez M., Colon-Mercado H., Olson L., Sridharan K. // Thin Solid Films. 2016. V. 615. P. 202. https://doi.org/10.1016/j.tsf.2016.07.024
Imtyazuddin M., Mir A.H., Tunes M.A., Vishnyakov V.M. // J. Nucl. Mater. 2019. V. 526. 151742. https://doi.org/10.1016/j.jnucmat.2019.151742
Kim M., Noh H., Lee G.C., Yeom H., Kim T.K., Kim J.M., Kim T.H., Jo H., Park H.S., Sridharan K., Kim M.H. // Appl. Thermal Engin. 2022. V. 207. P. 118164. https://doi.org/10.1016/j.applthermaleng.2022.118164
Yang J., Steinbrück M., Tang C., Große M., Liu J., Zhang J., Yun D., Wang S. // J. Alloys Compd. 2022. V. 895. P. 162450. https://doi.org/10.1016/j.jallcom.2021.162450
Wang W., Zhang G., Wang C., Wang T., Zhang Y., Xin T. // J. Alloys Compd. 2023. V. 946. P. 169385. https://doi.org/10.1016/j.jallcom.2023.169385
Fazi A., Sattari M., Stiller K., Andrén H.-O., Thuvander M. // J. Nucl. Mater. 2023. V. 576. P. 154268. https://doi.org/10.1016/j.jnucmat.2023.154268
Kane K., Bell S., Capps N., Garrison B., Shapovalov K., Jacobsen G., Deck C., Graening T., Koyanagi T., Massey C. // J. Nucl. Mater. 2023. V. 574. P. 154152. https://doi.org/10.1016/j.jnucmat.2022.154152
Syrtanov M., Kashkarov E., Abdulmenova A., Gusev K., Sidelev D. // Coatings. 2023. V. 13. № 1. P. 191. https://doi.org/10.3390/coatings13010191
Yang J., Steinbrück M., Tang C., Große M., Liu J., Zhang J., Yun D., Wang S. // J. Alloys Compd. 2022. V. 895. P. 162450. https://doi.org/10.1016/j.jallcom.2021.162450
Yang J., Stegmaier U., Tang C., Steinbrück M., Große M., Wang S., Seifert H.J. // J. Nucl. Mater. 2021. V. 547. P. 152806. https://doi.org/10.1016/j.jnucmat.2021.152806
Sidelev D.V., Poltronieri C., Bestetti M., Krinitcyn M.G., Grudinin V.A., Kashkarov E.B. // Surf. Coat. Technol. 2022. V. 433. P. 128134. https://doi.org/10.1016/j.surfcoat.2022.128134
Nelson A.T., Sooby E.S., Kim Y.-J., Cheng B., Maloy S.A. // J. Nucl. Mater. 2014. V. 448. Iss. 1–3. P. 441. https://doi.org/10.1016/j.jnucmat.2013.10.043
Sooby Wood E., Parker S.S., Nelson A.T., Maloy S.A. // J. Am. Ceram. Soc. 2016. V. 99. P. 1412. https://doi.org/10.1111/jace.14120
Гнесин И.Б., Гнесин Б.А., Некрасов А.Н., Прохоров Д.В., Гнесина Н.И., Карпов М.И., Желтякова И.С. // Поверхность. Рентген., синхротр. и нейтрон. исслед. 2022. № 1. С. 63. https://doi.org/10.31857/S1028096022010058
Gnesin I.B., Gnesin B.A., Nekrasov A.N., Prokhorov D.V., Gnesina N.I., Karpov M.I., Vershinin N.F., Kuznetsov S.V., Vnukov V.I., Zheltyakova I.S. // J. Surf. Invest.: X-ray, Synchrotron Neutron Tech. 2023. V. 17. № 1. P. 281. https://doi.org/10.1134/S1027451023010445
Sen Y., Mingrun W., Tao G., Wenjin L. // Key Engin. Mater. 2008. V. 373–374. P. 304.
Minasyan T., Ivanov R., Toyserkani E., Hussainova I. // J. Alloys Compd. 2021. V. 884. P. 161034. https://doi.org/10.1016/j.jallcom.2021.161034
Kiryukhantsev-Korneev Ph.V., Sytchenko A.D., Sviridova T.A., Sidorenko D.A., Andreev N.V., Klechkovskaya V.V., Polčak J., Levashov E.A. // Surf. Coat. Technol. 2022. V. 442. P. 128141. https://doi.org/10.1016/j.surfcoat.2022.128141
Nomura N., Suzuki T., Yoshimi K., Hanada S. // Intermetallics. 2003. V. 11. Iss. 7. P. 735. https://doi.org/10.1016/S0966-9795(03)00069-4
Fei X., Niu Y., Ji H., Huang L., Zheng X. // Ceram. Int. 2011. V. 37. Iss. 3. P. 813. https://doi.org/10.1016/j.ceramint.2010.10.018
Sun J., Fu Q.-G., Li T., Zhang G.-P., Yuan R.-M. // J. Alloys Compd. 2019. V. 776. P. 712. https://doi.org/10.1016/j.jallcom.2018.10.309
Gnesin I., Gnesin B., Nekrasov A. // J. Alloys Compd. 2018. V. 767. P. 803. https://doi.org/10.1016/j.jallcom.2018.07.193
Sakidja R., Park J.S., Hamann J., Perepezko J.H. // Scripta Materialia. 2005. V. 53. Iss. 6. P. 723. https://doi.org/10.1016/j.scriptamat.2005.05.015
Гнесина Н.И., Гнесин И.Б., Прохоров Д.В., Гнесин Б.А., Карпов М.И., Внуков В.И., Желтякова И.С., Строганова Т.С. // Сб. тр. 12-й Междунар. конф. “Фазовые превращения и прочность кристаллов”. Черноголовка, 24–27 октября 2022. С. 32.
