Study of the Acoustic Characteristics of Suspensions Based on Glycerol and Synthetic Diamond Microparticles Using a Resonator with a Longitudinal Electric Field

A. P. Semenov; Семёнов А. П.; B. D. Zaitsev; Зайцев Б. Д.; A. A. Teplykh; Теплых А. А.; I. A. Borodina; Бородина И. А.

doi:10.31857/S0320791923600294

Study of the Acoustic Characteristics of Suspensions Based on Glycerol and Synthetic Diamond Microparticles Using a Resonator with a Longitudinal Electric Field

Authors: Semenov A.P.¹, Zaitsev B.D.¹, Teplykh A.A.¹, Borodina I.A.¹
Affiliations:
1. Saratov Branch, Kotelnikov Institute of Radio Engineering and Electronics, Russian Academy of Sciences, Saratov, 410019 Russia
Issue: Vol 69, No 6 (2023)
Pages: 702-712
Section: ФИЗИЧЕСКАЯ АКУСТИКА
URL: https://journals.rcsi.science/0320-7919/article/view/233399
DOI: https://doi.org/10.31857/S0320791923600294
EDN: https://elibrary.ru/ZHNFZQ
ID: 233399

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The acoustic properties of suspensions based on pure glycerol and diamond powder with a particle size of 1–2 μm and different concentrations were studied using a resonator with a longitudinal electric field. A disk resonator made of langasite with round electrodes on both sides of the plate with a frequency of 4.1MHz, operating on a longitudinal acoustic wave, was completely immersed in a liquid container with the studied suspension. Based on the measured frequency dependences of the real and imaginary parts of the
electric impedance of the resonator using an equivalent electromechanical circuit, the longitudinal elastic modulus and longitudinal viscosity coefficient of the samples were determined. Comparison of the experimental dependences of the longitudinal elastic modulus, viscosity coefficient, and longitudinal acoustic wave
velocity on the volume concentration of diamond particles in the suspension with the calculated dependences demonstrated good agreement.

Keywords

piezoelectric resonator with a longitudinal electric field, suspensions, resonance frequency, electric impedance and admittance, elastic modulus, viscosity coefficient, longitudinal acoustic wave velocity
