GALLIUM NANOPARTICLES OBTAINED ON SILICON SUBSTRATES BY THERMAL EVAPORATION METHOD

G. N. Kozhemyakin; Кожемякин Г. Н.; Yu. S. Belov; Белов Ю. С.; M. K. Trufanova; Труфанова М. К.; V. V.  Artemov; Артемов В. В.; I. S. Volchkov; Волчков И. С.

doi:10.31857/S0023476123020091

GALLIUM NANOPARTICLES OBTAINED ON SILICON SUBSTRATES BY THERMAL EVAPORATION METHOD

Authors: Kozhemyakin G.N.¹, Belov Y.S.², Trufanova M.K.³, Artemov V.V.¹, Volchkov I.S.¹
Affiliations:
1. Shubnikov Institute of Crystallography, Federal Scientific and Research Center “Crystallography and Photonics,” Russian Academy of Sciences, Moscow, 119333 Russia
2. Bauman Moscow State Technical University, Kaluga Branch, Kaluga, 248000 Russia
3. Vladimir Dal Lugansk State University, Lugansk, 91034 Russia
Issue: Vol 68, No 2 (2023)
Pages: 313-318
Section: НАНОМАТЕРИАЛЫ, КЕРАМИКА
URL: https://journals.rcsi.science/0023-4761/article/view/137389
DOI: https://doi.org/10.31857/S0023476123020091
EDN: https://elibrary.ru/BQEGYD
ID: 137389

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

Gallium nanostructures have been obtained on silicon substrates by thermal evaporation in an argon atmosphere. The sizes, density, and shape of Ga particles have been determined by computer processing of electron SEM-images. The condensation of Ga on Si substrates for 10, 15, and 20 s ensured the formation of particles of several types: spherical, triangular, square, and in the form of rods and polyhedrons. The increase in the Ga condensation time to 20 s led to the increase in the density of spherical nanoparticles by 41%.
