MICROMORPHOLOGY OF THE LEAF EPIDERMIS SURFACE IN SOME PYRINAE SPECIES (ROSACEAE)

A. V. Babosha; Бабоша А. В.; A. S. Ryabchenko; Рябченко А. С.; T. Kh. Kumachova; Кумахова Т. Х.

doi:10.31857/S0006813623010027

MICROMORPHOLOGY OF THE LEAF EPIDERMIS SURFACE IN SOME PYRINAE SPECIES (ROSACEAE)

Authors: Babosha A.V.¹, Ryabchenko A.S.¹, Kumachova T.K.²
Affiliations:
1. Tsitsin Main Botanical Garden, Russian Academy of Sciences
2. Russian State Agrarian University – Moscow Timiryazev Agricultural Academy
Issue: Vol 108, No 1 (2023)
Pages: 23-36
Section: COMMUNICATIONS
URL: https://journals.rcsi.science/0006-8136/article/view/134313
DOI: https://doi.org/10.31857/S0006813623010027
EDN: https://elibrary.ru/LNHXBL
ID: 134313

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

Scanning electron microscopy (cryoSEM) was used to study the micromorphology of the leaf epidermis surface of species of 6 genera: Sorbus L., Aronia Medik., Amelanchier Medik., Cydonia Mill., Cotoneaster Medik., Crataegus L. (Rosaceae). The surface of the leaves of the studied plants has two types of cuticular folding. In C. melanocarpus and S. aucuparia, larger and sometimes branched single cuticular strands, usually located on one cell, were observed. In other species, the folding has the form of numerous smaller parallel microstrands running along the long axis of the cell. Different degree of manifestation of both types of cuticular folding was observed on the surface of main epidermal cells on one or both sides of the leaf blades. In addition, the stomata and trichomes were surrounded by radial striations. Microstrands in A. spicata and S. aucuparia were also present on papillae in the area of stomata. All the studied species show stomatal dimorphism. Larger primary stomata with more pronounced cuticular strands are located at some distance or in the center of a group of several smaller secondary stomata. The proportion of primary stomata ranged from 5 to 17%. In the studied species, there is a negative correlation between the stomata length and stomata density, which is close to such correlation in other taxa.

Keywords

microrelief, cuticular striation, trichomes, papillae, stomata, epidermis

References

Akçin Ö.E., Şenel G., Akçin Y. 2013. Leaf epidermis morphology of some Onosma (Boraginaceae) species from Turkey. – Turk. J. Bot. 37: 55–64. https://doi.org/10.3906/bot-1202-33
Assaad H., Zhou L., Carroll R.J., Wu G. 2014. Rapid publication-ready MS-Word tables for one-way ANOVA. – Springer Plus. 3: 474.
Babosha A.V., Kumachova T.K., Ryabchenko A.S., Komarova G.I. 2020. Stomata polymorphism in leaves of apple trees (Malus domestica Borkh.) growing under mountain and plain conditions. – Biology Bulletin. 47 (4): 352–363. https://doi.org/10.1134/S1062359020040032
Blanke M.M., Höfer M., Pring R.J. 1994. Stomata and structure of tetraploid apple leaves cultured in vitro. – Ann. of Bot. 73 (6): 651–654.
Boldt K.M., Rank B. 2010. Stomata dimorphism in dicotyledonous plants of temperate climate. – Feddes Repertorium. 121 (5–6): 167–183. https://doi.org/10.1002/fedr.201000023
Campbell C.S., Evans R.C., Morgan D.R., Dickinson T.A., Arsenault M.P. 2007. Phylogeny of subtribe Pyrinae (formerly the Maloideae, Rosaceae): limited resolution of a complex evolutionary history. – Plant Syst. Evol. 266: 119–145. https://doi.org/10.1007/s00606-007-0545-y
Carr S.G.M., Carr D.G. 1990. Cuticular features of the Central Australian bloodwoods Eucalyptus, section Corymbosae (Myrtaceae). – Bot. J. Linn. 102: 123–156.
Czerepanov S.K. 1995. Plantae vasculares rossiae et civitatum collimitanearum (in limicis URSS olim). St. Petersburg. 992 p.
Dehgan B. 1980. Application of epidermal morphology to taxonomic delimitations in the genus Jatropha L. (Euphorbiaceae). – Bot. J. Linn. Soc. 80: 257–278. https://doi.org/10.1111/j.1095-8339.1980.tb01989.x
Evert R.F., Eichhorn S.E. 2006. Esau’s plant anatomy: meristems, cells, and tissues of the plant body: their structure, function, and development, 3rd ed. – Hoboken, New Jersey, USA. 601 p.
Evert R.F. 2015. Anatomiya rasteniy Ezau. Meristemy, kletki i tkani rasteniy: stroenie, funkcii i razvitie. M. 600 p.
Fontenelle G.B., Costa C.G., Machado R.D. 1994. Foliar anatomy and micromorphology of eleven species of Eugenia L. (Myrtaceae). – Bot. J. Linn. Soc. 116: 111–133. https://doi.org/10.1006/bojl.1994.1056
Franks P.J., Farquhar G.D. 2007. The mechanical diversity of stomata and its significance in gas-exchange control. – Plant Physiol. 143 (1): 78–87. https://doi.org/10.1104/pp.106.089367
Franks P.J., Franks P.J., Drake P.L., Beerling D.J. 2009. Plasticity in maximum stomatal conductance constrained by negative correlation between stomatal size and density: an analysis using Eucalyptus globulus. – Plant Cell Environ. 32: 1737–1748. https://doi.org/10.1111/j.1365-3040.2009.002031.x
Giday H. et al. 2013. Smaller stomata require less severe leaf drying to close: a case study in Rosa hydrida. – J. Plant Physiol. 170: 1309–1316. https://doi.org/10.1016/j.jplph.2013.04.007
Kamelin R.V. 2006. Rozotsvetnyye (Rosaceae) [Rosaceae (Rosaceae)]. Barnaul. 100 p. (In Russ.).
Kumaсhova T.Kh., Beloshapkina O.O., Voronkov A.S., Ryabchenko A.S. 2019. Morphofunctional characteristics of leaves and fruits in Maloideae (Rosaceae): b. the role of surface tissues in the formation of resistance to fungal diseases. – Proceedings on Applied Botany, Genetics and Breeding. 180 (2): 95–101 (In Russ). https://doi.org/10.30901/2227-8834-2019-2-95-101
Kumachova T.Kh. et al. 2021. Leaf epidermis in Rosaceae: diversity of the сuticular folding and microstructure. – Proc. Natl. Acad. Sci., India Sect. B: Biol Sci. 91 (2): 455–470. https://doi.org/10.1007/s40011-021-01244-z
Miroslavov Ye.A. 1994. Structural adaptations of plants to cold climates. – Bot. Zhurn. 79 (2): 20–26 (In Russ.).
Miroslavov Ye.A., Kravkina Ye.M. 1990. Comparative anatomy of the leaf of plants growing in the mountains at different heights. – Bot. Zhurn. 75 (3): 368–375 (In Russ.).
Murtazaliyev R.A. 2009. Konspekt Flory Dagestana. [Synopsis of the Flora of Dagestan]. Vol. II. Makhachkala. 222 p. (In Russ.).
Pautov A.A. 2009. The role of morphogenetic correlations in the occurrence of heterostomacy. – Bot. Zhurn. 94 (6): 785–792 (In Russ.).
Pautov A.A. 2011. The location of microrelief folds on the side cells of the stomata of Hydrangea macrophylla (Thunb.) Ser. (Hydrangeaceae). – Vestnik SPbGU. 3 (2): 39–44 (In Russ.).
Pautov A.A., Arbicheva A.I., Yakovleva O.V. 2010. Correlations of leaf structure features of Agathis brownii Lem. – Vestnik SPbGU. 3 (3): 21–28 (In Russ.).
Pautov A.A., Vasil’yeva V.A. 2010. The role of the shape of the main cells of the epidermis in the morphogenesis of the leaf of representatives of Hamamelidaceae. – Bot. Zhurn. 95 (3): 338–344 (In Russ.).
Pautov A.A., Vasil’yeva V.A., Krylova Ye.G. 2015. Stomatal polymorphism in the leaf epidermis of Exbucklandia populnea (Hamamelidaceae) and its possible significance]. – Bot. Zhurn. 100 (6): 540–549 (In Russ.).
Pautov A., Bauer S., Ivanova O., Krylova E., Sapach Y., Gussarova G. 2017. Role of the outer stomatal ledges in the mechanics of guard cell movements. – Trees. 31 (1): 125–135. https://doi.org/10.1007/s00468-016-1462-x
Pautov A., Bauer S., Ivanova O., Krylova E., Yakovleva O., Sapach Y., Pautova I. 2019. Influence of stomatal rings on movements of guard cells. – Trees. 33 (5): 1459–1474. https://doi.org/10.1007/s00468-019-01873-y
Pautov A.A., Sapach Y.O., Ivanova O.V., Krylova E.G., 2014. Surface ornamentation in leaves of flowering plants: stomatal rims and ledges. – Bot. Zhurn. 99 (6): 625–640 (In Russ.).
Potter D., Eriksson T., Evans R.C., Oh S., Smed-mark J.E.E., Morgan D.R., … and Campbell C.S. 2007. Phylogeny and classification of Rosaceae. – Plant Syst. Evol. 266 (1): 5–43. https://doi.org/10.1007/s00606-007-0539-9
Ryabchenko A.S., Babosha A.V. 2011. Using thermal compound as adhesive and heat-conducting composition when analysing biological samples on scanning electron microscope using freezing attachments. RU patent 2445660.
Takhtajan A.L. et al. 1981. Zhizn’ rasteniy (Tsvetkovye rasteniya) [Plant life (Flowering plants)]. Moscow. Vol. 5 (2). P. 175–187 (In Russ.).
Takhtajan A. (ed.). 2009. Flowering plants. – Dordrecht, Netherlands. P. 293–324.
Ullah F., Ayaz A., Saqib S., Parmar G., Bahadur S., Zaman W. 2021. Taxonomic implication of leaf epidermal anatomy of selected taxa of Scrophulariaceae from Pakistan. – Microsc. Res. Tech. 84 (3): 521–530. https://doi.org/10.1002/jemt.23608
Xiang Y., Huang C.H., Hu Y., Wen J., Li S., Yi T., Chen H., Xiang J., Ma H. 2017. Evolution of Rosaceae fruit types based on nuclear phylogeny in the context of geological times and genome duplication. – Mol. Biol. Evol. 34 (2): 262–281. https://doi.org/10.1093/molbev/msw242
Zhang S.D., Jin J.J., Chen S.Y., Chase M.W., Soltis D.E., Li H.T., Yang J.B., Li D.Z., Yi T.S. 2017. Diversification of Rosaceae since the Late Cretaceous based on plastid phylogenomics. – New Phytol. 214 (3): 1355–1367. https://doi.org/10.1111/nph.14461
Zitte, P., Vailer, E.V., Kaderait, I.V., Brezinski, A., Kerner, K. 2007. Botanika. Uchebnik dlya vuzov. Tom 4: Ekologiya. M. 256 p. (In Russ.).
