Микроструктура и ударная вязкость игольчатого феррита в сварных соединениях низколегированной стали по результатам множественных испытаний на ударный изгиб

Обложка

Цитировать

Полный текст

Открытый доступ Открытый доступ
Доступ закрыт Доступ предоставлен
Доступ закрыт Только для подписчиков

Аннотация

Путем анализа результатов испытания на ударный изгиб большого количества образцов исследовано разрушение металла сварного шва, преимущественно состоящего из игольчатого феррита. Исследованный металл обладает очень широким интервалом вязко-хрупкого перехода, начинающимся при +20 и заканчивающимся ниже –60°C. В пределах исследованных температур наблюдаются 3 стабильных уровня ударной вязкости, переходы между которыми с понижением температуры определяют рассеяние работы разрушения образцов. Фрактографически вязко-хрупкий переход осуществляется за счет однократного изменения с вязкого механизма разрушения на скол. Зарождение трещин скола происходит на крупных зернах игольчатого феррита, различное взаиморасположение которых в очаге скола определяет уровень ударной вязкости образца. Путем сопоставления динамических кривых разрушения и макростроения излома показано, что трещины скола зарождаются в вершине стабильно растущей вязкой трещины. При этом на изломах можно выделить отдельные события скола, наблюдаемые на динамической кривой.
