An experimental study of the stress-strain state of the engine piston skirt on the engineless stand
- Авторлар: Smirnov S.V.1, Kopylov V.V.1, Makarov A.R.1, Vorobyev A.A.1, Shkarin K.V.1
-
Мекемелер:
- Peoples’ Friendship University of Russia (RUDN University)
- Шығарылым: Том 20, № 4 (2019)
- Беттер: 285-292
- Бөлім: Mechanical engineering and machine science
- URL: https://journals.rcsi.science/2312-8143/article/view/335224
- DOI: https://doi.org/10.22363/2312-8143-2019-20-4-285-292
- ID: 335224
Дәйексөз келтіру
Толық мәтін
Аннотация
The article describes the features developed by the authors of the profiling method of the piston skirt, provides the main parameters that affect the lubrication conditions of the piston skirt and the magnitude of mechanical losses. In computational studies, the basic formulas are given for determining the thickness of the oil layer in a piston skirt - cylinder sleeve conjunction to assess the nature of friction. To determine the deformations, the finite element method is used on the spatial model of the piston. To verify the finite element model, a stand for experimental studies was developed. The article describes the developed stand, the methodology and results of experimental studies of the stress-strain state of the two-piece piston skirt obtained at this stand and a comparative analysis of the results of the calculated and experimental studies of the stress-strain state of the two-piece piston skirt of a diesel engine. The research results showed that the developed stand can be used to verify mathematical models for calculating the stress-strain state of the piston skirt in the pilot production of internal combustion engine pistons to accelerate and reduce the cost of the piston design development process, as well as the results of experimental studies obtained at the stand, can be used as initial data for the developed mathematical model of the dynamics of the movement of the piston and the profiling of the piston skirt.
Авторлар туралы
Sergei Smirnov
Peoples’ Friendship University of Russia (RUDN University)
Хат алмасуға жауапты Автор.
Email: smirnov-sv@rudn.ru
Associate Professor at the Department of Mechanical Engineering and Instrument Engineering of Engineering Academy of RUDN University, Candidate of Technical Sciences
6 Miklukho-Maklaya St., Moscow, 117198, Russian FederationVladimir Kopylov
Peoples’ Friendship University of Russia (RUDN University)
Email: smirnov-sv@rudn.ru
Associate Professor at the Department of Mechanical Engineering and Instrument Engineering of Engineering Academy of RUDN University, Candidate of Technical Sciences
6 Miklukho-Maklaya St., Moscow, 117198, Russian FederationAlexander Makarov
Peoples’ Friendship University of Russia (RUDN University)
Email: smirnov-sv@rudn.ru
Professor at the Department of Mechanical Engineering and Instrument Engineering of Engineering Academy of RUDN University, Candidate of Technical Sciences
6 Miklukho-Maklaya St., Moscow, 117198, Russian FederationAlexander Vorobyev
Peoples’ Friendship University of Russia (RUDN University)
Email: smirnov-sv@rudn.ru
postgraduate student of the Department of Mechanical Engineering and Instrument Engineering of Engineering Academy of RUDN University
6 Miklukho-Maklaya St., Moscow, 117198, Russian FederationKirill Shkarin
Peoples’ Friendship University of Russia (RUDN University)
Email: smirnov-sv@rudn.ru
Assistant of Department of Mechanical and Instrument Engineering of Engineering Academy of RUDN University
6 Miklukho-Maklaya St., Moscow, 117198, Russian FederationӘдебиет тізімі
- Danilov IK, Popova IM, Moiseev UI. Analysis and validation of the dynamic method for diagnosing diesel engine connecting rod bearings. Transport Problems. 2018;13(1):123–133.
- Putintsev SV. Mekhanicheskie poteri v porshnevykh dvigatelyakh: spetsial'nye glavy konstruirovaniya, rascheta i ispytanii [Mechanical losses in piston engines: special chapters in the design, calculation and testing]. Moscow: MGTU imeni N.E. Baumana; 2011. (In Russ.)
- Putintsev SV, Ageev AG. Proverka effektivnosti primeneniya reber zhestkosti yubki porshnya malorazmernogo dizelya [Efficiency checking of use of stiffening ribs for piston skirt of a low-sized diesel engine]. Tractors and agricultural machinery. 2016;11:35–39. (In Russ.)
- Kim K. A Study of Friction and Lubrication Behavior for Gasoline Piston Skirt Profile Concepts. Part 3. SAE Technical Paper. 2009;(01-0193):1–5.
- Doikin AA. Raschetno-eksperimental'nyi metod profilirovaniya obrazuyushchei porshnya dlya povysheniya resursa tribosopryazheniya “porshen' – tsilindr” DVS [Calculation and experimental method for profiling a piston generatrix to increase the piston-cylinder tribo-conjugation resource] (PhD dissertation). Chelyabinsk; 2013. (In Russ.)
- Abbes MT, Maspeyrot P, Dekkiche A, Benbrik M, Hacene FB. Elastohydrodynamic Piston Skirt Lubrication: Effect on Tribological Performances. ASME/STLE International Joint Tribology Conference. 2012. p. 237–242. doi: 10.1115/IJTC2012-61129.
- Zhenpeng H. Piston skirt friction loss and dynamic analyses based on FEM method. Industrial Lubrication and Tribology. 2018;70(4):656–672.
- Ageev AG. Zavisimost' dliny yubki porshnya ot skorostnogo rezhima raboty dvigatelya [The dependence of the piston skirt length on the high-speed engine]. Molodezhnyi nauchno-tekhnicheskii vestnik MGTU imeni N.E. Baumana [Politechnical student journal of BMSTU]. 2013;(2):6–10. (In Russ.)
- Allmaier H, Sander DE, Reich FM. Measuring friction in automotive engines & determining the contributions of the individual subsystems. World Tribology Congress. Torino; 2013. p. 117.
- Rahnejat H. Tribology and dynamics of engine and powertrain: fundamentals, applications and future trends. Elsevier; 2010.
- Makarov AR, Smirnov SV, Osokin SV. Matematicheskoe modelirovanie dvizheniya porshnya v tsilindre [Mathematical modeling of piston movement in a cylinder]. Izvestiya MGTU “MAMI”. 2014.;2(20):24–30. (In Russ.)
- Kostrov AV, Smirnov SV, Makarov AR. Matematicheskoe modelirovanie dvizheniya porshnya v tsilindre v sloe smazochnogo materiala s uchetom deformatsii yubki [Mathematical modeling of dynamics movement of a piston skirt in the cylinder of the internal combustion engine]. Dvigatelestroenie. 1990;(1):7–9 (In Russ.)
- Smirnov SV, Makarov AR, Vorobyev AA. Matematicheskoe modelirovanie dinamiki dvizheniya yubki porshnya v tsilindre dvigatelya vnutrennego sgoraniya [Mathematical modeling of dynamics movement of a piston skirt in the cylinder of the internal combustion engine]. RUDN Journal of Engineering Researches. 2017;18(3): 338–344. doi: 10.22363/2312-8143-2017-18-3-338-344. (In Russ.)
- Mekheda VA. Tenzometricheskii metod izmereniya deformatsii [Strain-gauge method deformation measurement]: textbook. Samara: Samara State Aerospace University; 2011. (In Russ.)
