电邮这篇文章 Theoretical assessment of the stability of a digital thermocompensated quartz oscillator with temperature sensor based on two auxiliary quartz oscillators
- 作者: Kulyasov S.M.1, Chetter D.M.1, Lyashuk A.N.1
-
隶属关系:
- Omsk State Technical University
- 期: 卷 192, 编号 4 (2024)
- 页面: 139-149
- 栏目: ELECTRONICS, PHOTONICS, INSTRUMENT ENGINEERING AND CONNECTION
- URL: https://journals.rcsi.science/1813-8225/article/view/279209
- DOI: https://doi.org/10.25206/1813-8225-2024-192-139-149
- EDN: https://elibrary.ru/ENIHOV
- ID: 279209
如何引用文章
全文:
详细
The article provides a theoretical limit assessment of the stability of a digital thermocompensated quartz oscillator with a temperature sensor based on two auxiliary quartz oscillators. The results are 7,5 ppb (for a restless environment) and 0,75 ppb (for a calm environment). Technical solutions are considered for obtaining a linear one-to-one dependence of the difference frequency value on temperature and increasing the steepness of this dependence. The proposed solutions allow obtaining a temperature measurement resolution of up to 0,001 ºС.
