Neutron Source from (γ,n) Reactions at a Laser-Plasma Accelerator and Its Use for Electron Beam Characterization
- 作者: Gorlova D.1,2, Zavorotny A.1,2, Tsymbalov I.1,2, Ivanov K.1,3, Shulyapov S.1,4, Volkov R.1, Savel’ev A.1,3
-
隶属关系:
- Faculty of Physics, Lomonosov Moscow State University
- Institute for Nuclear Research of Russian Academy of Sciences
- Lebedev Physical Institute of Russian Academy of Sciences
- N.N. Andreyev Acoustics Institute of Russian Academy of Sciences
- 期: 编号 8 (2023)
- 页面: 22-31
- 栏目: Articles
- URL: https://journals.rcsi.science/1028-0960/article/view/137793
- DOI: https://doi.org/10.31857/S1028096023080083
- EDN: https://elibrary.ru/OBZOPU
- ID: 137793
如何引用文章
详细
Development of compact laboratory-scale neutron sources is of importance both for fundamental physical research and practical applications (for example, neutron radiography and spectroscopy). One of the most promising approaches to the development of such a source is the implementation of laser-plasma accelerated electrons or ions, and the subsequent initiation of nuclear reactions (γ,n), (p,n) or (d,n) with the emission of neutrons. In the present work, a neutron source produced via photodisintegration reactions (γ,n) using an electron beam from a one TW laser-plasma accelerator has been created and characterized. Maximum observed neutron flux was ~105 neutrons/s · srad with a ~106 neutrons per J of laser radiation efficiency. With constant efficiency and 10 times increase in the laser pulse energy the neutron flux will be sufficient for certain applications. Numerical Monte-Carlo simulations of neutron generation by an electron beam with parameters corresponding to those measured experimentally were also carried out. It was demonstrated that the number of generated neutrons can be used to estimate the charge and average energy of accelerated electrons. The obtained values are in good agreement with the values measured by the standard beam diagnostic tools.
作者简介
D. Gorlova
Faculty of Physics, Lomonosov Moscow State University; Institute for Nuclear Research of Russian Academy of Sciences
编辑信件的主要联系方式.
Email: gorlova.da14@physics.msu.ru
Russia, 119991, Moscow; Russia, 117312, Moscow
A. Zavorotny
Faculty of Physics, Lomonosov Moscow State University; Institute for Nuclear Research of Russian Academy of Sciences
Email: gorlova.da14@physics.msu.ru
Russia, 119991, Moscow; Russia, 117312, Moscow
I. Tsymbalov
Faculty of Physics, Lomonosov Moscow State University; Institute for Nuclear Research of Russian Academy of Sciences
Email: gorlova.da14@physics.msu.ru
Russia, 119991, Moscow; Russia, 117312, Moscow
K. Ivanov
Faculty of Physics, Lomonosov Moscow State University; Lebedev Physical Institute of Russian Academy of Sciences
Email: gorlova.da14@physics.msu.ru
Russia, 119991, Moscow; Russia, 119991, Moscow
S. Shulyapov
Faculty of Physics, Lomonosov Moscow State University; N.N. Andreyev Acoustics Institute of Russian Academy of Sciences
Email: gorlova.da14@physics.msu.ru
Russia, 119991, Moscow; Russia, 117292, Moscow
R. Volkov
Faculty of Physics, Lomonosov Moscow State University
Email: gorlova.da14@physics.msu.ru
Russia, 119991, Moscow
A. Savel’ev
Faculty of Physics, Lomonosov Moscow State University; Lebedev Physical Institute of Russian Academy of Sciences
Email: gorlova.da14@physics.msu.ru
Russia, 119991, Moscow; Russia, 119991, Moscow
参考
- Gales S., Tanaka K.A., Balabanski D.L., Negoita F., Stutman D., Tesileanu O., Ur C.A., Ursescu D., Andrei I., Ataman S. et al. // Reports Prog. Phys. 2018. V. 81. № 9. P. 094301. https://www.doi.org/10.1088/1361-6633/AACFE8
- Umstadter D. // J. Phys. D. Appl. Phys. 2003. V. 36. № 8. P. R151. https://www.doi.org/10.1088/0022-3727/36/8/202
- Alejo A., Ahmed H., Green A., Mirfayzi S.R., Borghesi M., Kar S. // Nuovo Cim. della Soc. Ital. di Fis. C. 2015. V. 38. № 6. P. 1. https://www.doi.org/10.1393/ncc/i2015-15188-8
- Nedorezov V.G., Rykovanov S.G., Savel’ev A.B. // Uspekhi Fiz. Nauk. 2021. T. 191. C. 1281. https://www.doi.org/10.3367/ufnr.2021.03.038960
- Filges D., Goldenbaum F. // Handbook of Spallation Research. Germany, Wiley, Weinheim, 2009.
- Altieri S., Protti N. // Ther. Radiol. Oncol. 2018. V. 2. P. 47. https://www.doi.org/10.21037/TRO.2018.10.08
- Ковальчук М.В., Воронин В.В., Гаврилов С.В., Гартвик А.В., Дьячков М.В., Ипатов Д.А., Матвеев В.А., Тарнавич В.В., Ульянов В.А. // Кристаллография. 2022. Т. 67. № 5. С. 785. https://www.doi.org/10.31857/S0023476122050095
- Anderson I.S., Andreani C., Carpenter J.M., Festa G., Gorini G., Loong C.K., Senesi R. // Phys. Rep. 2016. V. 654. P. 1. https://www.doi.org/10.1016/J.PHYSREP.2016.07.007
- Ikeda Y., Taketani A., Takamura M., Sunaga H., Kumagai M., Oba Y., Otake Y., Suzuki H. // Nucl. Instrum. Methods Phys. Res. A. 2016. V. 833. P. 61. https://www.doi.org/10.1016/J.NIMA.2016.06.127
- Alvarez J., Fernández-Tobias J., Mima K., Nakai S., Kar S., Kato Y., Perlado J.M. // Phys. Procedia. C. 2014. V. 60. P. 29. https://www.doi.org/10.1016/j.phpro.2014.11.006
- Kleinschmidt A., Bagnoud V., Deppert O., Favalli A., Frydrych S., Hornung J., Jahn D., Schaumann G., Tebartz A., Wagner F. et al. // Phys. Plasmas. 2018. V. 25. № 5. P. 053101. https://www.doi.org/10.1063/1.5006613
- Ivanov K.A., Shulyapov S.A., Gorlova D.A., Mordvintsev I.M., Tsymbalov I.N., Savel’ev A.B. // Quantum Electron. 2021. V. 51. № 9. P. 768. https://www.doi.org/10.1070/QEL17604/XML
- Feng J., Fu C., Li Y., Zhang X., Wang J., Li D., Zhu C., Tan J., Mirzaie M., Zhang Z. et al. // High Energy Density Phys. 2020. V. 36. P. 100753. https://www.doi.org/10.1016/j.hedp.2020.100753
- Arikawa Y., Utsugi M., Alessio M., Nagai T., Abe Y., Kojima S., Sakata S., Inoue H., Fujioka S., Zhang Z. et al. // Plasma Fusion Res. 2015. V. 10. Iss. 1. P. 2404003. https://www.doi.org/10.1585/pfr.10.2404003
- Phillips T.W., Cable M.D., Cowan T.E., Hatchett S.P., Henry E.A., Key M.H., Perry M.D., Sangster T.C., Stoyer M.A. // Rev. Sci. Instrum. 1999. V. 70. № 1. P. 1213. https://www.doi.org/10.1063/1.1149337
- Mirfayzi S.R., Yogo A., Lan Z., Ishimoto T., Iwamoto A., Nagata M., Nakai M., Arikawa Y., Abe Y., Golovin D. et al. // Sci. Rep. 2020. V. 10. № 1. P. 20157. https://www.doi.org/10.1038/s41598-020-77086-y
- Mirfayzi S.R., Ahmed H., Doria D., Alejo A., Ansell S., Clarke R.J., Gonzalez-Izquierdo B., Hadjisolomou P., Heathcote R., Hodge T. et al. // Appl. Phys. Lett. 2020. V. 116. № 17. P. 174102. https://www.doi.org/10.1063/5.0003170
- Jung D., Falk K., Guler N., Deppert O., Devlin M., Favalli A., Fernandez J.C., Gautier D.C., Geissel M., Haight R. et al. // Phys. Plasmas. 2013. V. 20. № 5. P. 056706. https://www.doi.org/10.1063/1.4804640
- Higginson D.P., McNaney J.M., Swift D.C., Bartal T., Hey D.S., Kodama R., Le Pape S., MacKinnon A., Mariscal D., Nakamura H. et al. // Phys. Plasmas. 2010. V. 17. № 10. P. 100701. https://www.doi.org/10.1063/1.3484218
- Günther M.M., Rosmej O.N., Tavana P., Gyrdymov M., Skobliakov A., Kantsyrev A., Zähter S., Borisenko N.G., Pukhov A., Andreev N.E. // Nature Commun. 2022. V. 13. № 131. P. 1. https://www.doi.org/10.1038/s41467-021-27694-7
- Horn’y V., Chen S.N., Davoine X., et al. // High-flux neutron generation by laser-accelerated ions from single- and double-layer targets. Sci Rep 12, 19767 (2022). https://doi.org/10.1038/s41598-022-24155-z
- Magill J., Schwoerer H., Ewald F., Galy J., Schenkel R., Sauerbrey R.// Appl. Phys. B. 2003. V. 77. № 4. P. 387. https://www.doi.org/10.1007/S00340-003-1306-4
- Tsymbalov I.N., Volkov R.V., Eremin N.V., Ivanov K.A., Nedorezov V.G., Paskhalov A.A., Polonskij A.L., Savel’ev A.B., Sobolevskij N.M., Turinge A.A. et al. // Phys. At. Nucl. 2017. V. 80. № 3. P. 397. https://www.doi.org/10.1134/S1063778817030231
- Malka G., Aleonard M.M., Chemin J.F., Claverie G., Harston M.R., Scheurer J.N., Tikhonchuk V., Fritzler S., Malka V., Balcou P. et al. // Phys. Rev. E. 2002. V. 66. № 6. P. 066402. https://www.doi.org/10.1103/PhysRevE.66.066402
- Ledingham K.W.D., Spencer I., McCanny T., Singhal R.P., Santala M.I.K., Clark E., Watts I., Beg F.N., Zepf M., Krushelnick K. et al. // Phys. Rev. Lett. 2000. V. 84. № 5. P. 899. https://www.doi.org/10.1103/PhysRevLett.84.899
- Tsymbalov I., Gorlova D., Ivanov K., Shulyapov S., Prokudin V., Zavorotny A., Volkov R., Bychenkov V., Nedorezov V., Savel’ev A. et al. // Plasma Phys. Control. Fusion. 2021. V. 63. № 2. P. 022001. https://www.doi.org/10.1088/1361-6587/abcc3c
- Tsymbalov I., Gorlova D., Shulyapov S., Prokudin V., Zavorotny A., Ivanov K., Volkov R., Bychenkov V., Nedorezov V., Paskhalov A. et al. // Plasma Phys. Control. Fusion. 2019. V. 61. № 7. P. 075016. https://www.doi.org/10.1088/1361-6587/ab1e1d
- Tsymbalov I.N., Volkov R.V., Eremin N.V., Ivanov K.A., Nedorezov V.G., Paskhalov A.A., Polonskij A.L., Savel’ev A.B., Sobolevskij N.M., Turinge A.A. et al. // Phys. At. Nucl. 2017. V. 80. № 3. P. 397. https://www.doi.org/10.1134/S1063778817030231
- Gorlova D., Tsymbalov I., Ivanov K., Zavorotnyi A., Nedorezov V., Savel’ev A. // Proc. SPIE 2021. V. 11779. https://doi.org/10.1117/12.2589123
- Agostinelli S., Allison J., Amako K., Apostolakis J., Araujo H., Arce P., Asai M., Axen D., Banerjee S., Barrand G. et al. // Nucl. Instrum. Methods Phys. Res. A. 2003. V. 506. № 3. P. 250. https://doi.org/10.1016/S0168-9002(03)01368-8
- Chadwick M.B., Herman M., Obložinský P., Dunn M.E., Danon Y., Kahler A.C., Smith D.L., Pritychenko B., Arbanas G., Arcilla R. et al. // Nucl. Data Sheets. 2011. V. 112. № 12. P. 2887. https://www.doi.org/10.1016/J.NDS.2011.11.002
- Kutsenko B. New Geant4 photonuclear cross-section model. https://cds.cern.ch/record/2778865/.
- Otuka N., Dupont E., Semkova V., Pritychenko B., Blokhin A.I., Aikawa M., Babykina S., Bossant M., Chen G., Dunaeva S. et al. // Nucl. Data Sheets. 2014. V. 120. P. 272. https://www.doi.org/10.1016/J.NDS.2014.07.065
- Kawano T., Cho Y.S., Dimitriou P., Filipescu D., Iwamoto N., Plujko V., Tao X., Utsunomiya H., Varlamov V., Xu R. et al. // Nucl. Data Sheets. 2020. V. 163. P. 109. https://www.doi.org/10.1016/J.NDS.2019.12.002
