Kinetic Theory of Expansion of Two-Component Plasma in a Plane Vacuum Diode
- Authors: Kokovin A.O.1, Kozhevnikov V.Y.1, Kozyrev A.V.1, Igumnov V.S.1, Semenyuk N.S.1
-
Affiliations:
- Institute of High Current Electronics of the Siberian Branch of the Russian Academy of Sciences
- Issue: No 6 (2023)
- Pages: 183-191
- Section: Articles
- URL: https://journals.rcsi.science/1024-7084/article/view/231751
- DOI: https://doi.org/10.31857/S1024708423600446
- EDN: https://elibrary.ru/VAMYHA
- ID: 231751
Cite item
Abstract
The results of study of the initial stage of expansion of a collisionless plasma with the electric current into a plane vacuum gap on the basis of kinetic equations for electrons and ions and the Poisson equation for the electric field are given. Self-consistent dynamics of a two-component plasma and electric field are theoretically modeled and the fundamental mechanism for establishing superthermal velocities of charged particles is described in detail. The parameters of anode-directed flows of positive ions in the cathode plume plasma are calculated. The expansion velocities of the cathode plume plasma observed in vacuum arcs at the level of (1−5) × 106 cm/s can be explained within the framework of the proposed collisionless mechanism.
About the authors
A. O. Kokovin
Institute of High Current Electronics of the Siberian Branch of the Russian Academy of Sciences
Email: Vasily.Y.Kozhevnikov@ieee.org
Tomsk, Russia
V. Yu. Kozhevnikov
Institute of High Current Electronics of the Siberian Branch of the Russian Academy of Sciences
Email: Vasily.Y.Kozhevnikov@ieee.org
Tomsk, Russia
A. V. Kozyrev
Institute of High Current Electronics of the Siberian Branch of the Russian Academy of Sciences
Email: Vasily.Y.Kozhevnikov@ieee.org
Tomsk, Russia
V. S. Igumnov
Institute of High Current Electronics of the Siberian Branch of the Russian Academy of Sciences
Email: Vasily.Y.Kozhevnikov@ieee.org
Tomsk, Russia
N. S. Semenyuk
Institute of High Current Electronics of the Siberian Branch of the Russian Academy of Sciences
Author for correspondence.
Email: Vasily.Y.Kozhevnikov@ieee.org
Tomsk, Russia
References
- Boxman R.L., Sanders D., Martin P. Vacuum Arc Science and Technology. Noyes, Park Ridge, NJ. 1995. 539 p.
- Месяц Г.А. Взрывная электронная эмиссия. М.: Физматлит. 2011. 280 с.
- Hantzsche E. Mysteries of the arc cathode spot: A retrospective glance // IEEE Trans. on Plasma Science. 2003. V. 31. № 531. P. 799–808.
- Oks E.M., Savkin K.P., Yushkov G.Y., Nikolaev A.G., Anders A. and Brown I.G. Measurement of total ion current from vacuum arc plasma sources // Rev. Sci. Instr. 2006. V. 77. № 3. P. 03B504.
- Окс Е.М., Юшков Г.Ю., Бугаев А.С., Кринберг И.А. О механизме ускорения ионов в плазме вакуумного дугового разряда // ДАН. 2001. Т. 378. № 1. С. 41–43.
- Anders A. Ion charge state distributions of vacuum arc plasmas: The origin of species // Phys. Rev. E. 1997. V. 55. № 1. P. 969–981.
- Власов А.А. О вибрационных свойствах электронного газа // УФН. 1967. Т. 93. № 3. С. 444–470.
- Kozhevnikov V.Yu., Kozyrev A.V., Semeniuk N.S. Modeling of Space Charge Effects in Intense Electron Beams: Kinetic Equation Method Versus PIC Method // IEEE Trans. on Plasma Science. 2017. V. 45. № 10. P. 2762–2766.
- Xiong T., Qiu J.M., Xu Z., Christlieb A. High order maximum principle preserving semi-Lagrangian finite difference WENO schemes for the Vlasov equation // J. Comp. Phys. 2014. V. 273. P. 618–639.
- Yoshida H. Construction of higher order symplectic integrators // Phys. Lett. A. 1990. V. 150. № 5. P. 262–268.
- Калиткин Н.Н., Альшин А.Б., Альшина Е.А., Рогов Б.В. Вычисления на квазиравномерных сетках. М.: Физматлит. 2005. 224 с.
- Kozyrev A., Kozhevnikov V., Semeniuk N. Why do Electrons with “Anomalous Energies” appear in High-Pressure Gas Discharges? // EPJ Web of Conferences. 2018. V. 167. P. 01005.
- Zubarev N.M., Kozhevnikov V.Y., Kozyrev A.V., Mesyats G.A., Semeniuk N.S., Sharypov K.A. Mechanism and dynamics of picosecond radial breakdown of a gas-filled coaxial line // Plasma Sour. Sci. Tech. 2020. V. 29. № 12. P. 125008.
- Баренгольц С.А., Казаринов Н.Ю., Месяц Г.А., Перельштейн Э.А., Шевцов В.Ф. Моделирование процесса формирования глубокой потенциальной ямы в вакуумном диоде // Письма в ЖТФ. 2005. Т. 31. № 4. С. 64–70.
- Михайловский А.Б. Теория плазменных неустойчивостей: Т. 1 // М.: Атомиздат, 1970. 294 с.
