The influence of magnetic film anisotropy on the frequency-modulated signal detection

F. F. Asadullin; Асадуллин Ф. Ф.; D. A. Pleshev; Плешев Д. А.; V. S. Vlasov; Власов В. С.; V. I. Shcheglov; Щеглов В. И.

doi:10.31857/S0367676522700673

The influence of magnetic film anisotropy on the frequency-modulated signal detection

作者: Asadullin F.¹, Pleshev D.¹^,2, Vlasov V.², Shcheglov V.³
隶属关系:
1. Saint Petersburg State Forestry University
2. Syktyvkar State University
3. Kotelnikov Institute of Radio Engineering and Electronics of the Russian Academy of Sciences
期: 卷 87, 编号 3 (2023)
页面: 383-389
栏目: Articles
URL: https://journals.rcsi.science/0367-6765/article/view/135301
DOI: https://doi.org/10.31857/S0367676522700673
EDN: https://elibrary.ru/HGHRMU
ID: 135301

如何引用文章

全文:

开放存取

##reader.subscriptionAccessGranted##
受限制的访问

订阅存取

详细
作者简介
参考
补充文件
统计

详细

We studied the possibility of using a magnetostriction converter for detecting a microwave signal with frequency modulation. The magnetization vector and elastic displacement oscillations in a normally magnetized ferrite film with crystallographic anisotropy are considered. We analyzed the effect of crystallographic cell orientation on the nature of the magnetization dynamics and elastic displacement oscillations, the establishment of various oscillation modes, and the detection process.

作者简介

F. Asadullin

Saint Petersburg State Forestry University

编辑信件的主要联系方式.
Email: aff@sfi.komi.com
Russia, 194021, St. Petersburg

D. Pleshev

Saint Petersburg State Forestry University; Syktyvkar State University

Email: aff@sfi.komi.com
Russia, 194021, St. Petersburg; Russia, 167001, Syktyvkar

V. Vlasov

Syktyvkar State University

Email: aff@sfi.komi.com
Russia, 167001, Syktyvkar

V. Shcheglov

Kotelnikov Institute of Radio Engineering and Electronics of the Russian Academy of Sciences

Email: aff@sfi.komi.com
Russia, 125009, Moscow

参考

Голямина И.П. Физика и техника мощного ультразвука. Кн. 1. Источники мощного ультразвука. М.: Наука, 1967. С. 111.
Comstock R.L., LeCraw R.C. // J. Appl. Phys. 1963. V. 34. No. 10. P. 3022.
Eshbach J.R. // JAP. 1963. V. 34. No. 4. P. 1298.
Schlömann E., Joseph R.I., Kohane T. // Proc. IEEE. 1965. V. 53. No. 10. P. 1495.
Семенцев Д.И., Шутый А.М. // УФН. 2007. Т. 177. № 8. С. 831; Sementsov D.I., Shutyi A.M. // Phys. Usp. 2007. V. 50. P. 793.
Гуляев Ю.В., Зильберман П.Е., Темирязев А.Г., Тихомирова М.П. // ФТТ. 2000. Т. 42. № 6. С. 1062; Gulyaev Yu.V., Zil’berman P.E., Temiryazev A.G., Tikhomirova M.P. // Phys. Solid State. 200. V. 42. No. 6. P. 1094.
Kirushev M.S., Vlasov V.S., Kotov L.N. et al. // Solid State Phenom. 2015. V. 233–234. P. 73.
Chang C.L., Tamming R.R., Broomhall T.J., Janusonis J. // Phys. Rev. Appl. 2018. V. 10. No. 3. Art. No. 034068.
Wei-Gang Yang, Holger Schmidt // Appl. Phys. Rev. 2021. V. 8. Art. No. 021304.
Локк Э.Г., Герус С.В., Анненков А.Ю. // Радиотехн. и электрон. 2018. Т. 63. № 10. С. 1089; Lokk E.G., Gerus S.V., Annenkov A.Yu. // J. Commun. Technol. Electron. 2018. V. 63. No. 10. P. 1197.
Чупров И.А., Асадуллин Ф.Ф., Плешев Д.А. и др. // Челябин. физ.-мат. журн. 2021. Т. 6. № 2. С. 237.
Плешев Д.А., Асадуллин Ф.Ф., Власов В.С. и др. // Физ. мет. и металловед. 2022. Т. 123. № 3. С. 320; Pleshev D.A., Asadullin F.F., Vlasov V.S. et al. // Phys. Metal. Metallogr. 2022. V. 123. No. 3. P. 276.
Власов В.С., Плешев Д.А., Шавров В.Г., Щеглов В.И. // Журн. радиоэлектрон. 2020. № 7. С. 8.
