Reflection of the Electromagnetic Wave from the Region of Electron Cyclotron Absorption in Thermonuclear Plasma

E. D. Gospodchikov; Господчиков Е. Д.; P. A. Chuvakin; Чувакин П. А.; A. G. Shalashov; Шалашов А. Г.

doi:10.31857/S0367292123600887

Reflection of the Electromagnetic Wave from the Region of Electron Cyclotron Absorption in Thermonuclear Plasma

Authors: Gospodchikov E.D.¹, Chuvakin P.A.¹, Shalashov A.G.¹
Affiliations:
1. Gaponov-Grekhov Institute of Applied Physics, Russian Academy of Sciences
Issue: Vol 49, No 10 (2023)
Pages: 953-963
Section: СТЕЛЛАРАТОРЫ
URL: https://journals.rcsi.science/0367-2921/article/view/232767
DOI: https://doi.org/10.31857/S0367292123600887
EDN: https://elibrary.ru/EHMULR
ID: 232767

Cite item

Full Text

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

A new approach to the problem of the passage of the extraordinary wave through the region of the electron–cyclotron resonance in inhomogeneous plasma was considered in the framework of the full set of Maxwell’s equations, taking into account the effects of spatial dispersion and resonance dissipation. For the model one-dimensional geometry, field distributions were calculated in the vicinity of the cyclotron resonance at the second harmonic for the normal incidence of the extraordinary wave and the reflection, transmission, and absorption coefficients were found depending on the parameters of the resonance region. As a result, the fine effect of the reflection of electromagnetic radiation from the cyclotron resonance region in transparent plasma was described and the results were compared with the observations of this effect in the experiments on the microwave heating of the plasma at the L-2M stellarator.

Keywords

high-temperature plasma, electron-cyclotron resonance, second harmonic, full-wave simulations, quasielectrostatic waves

References

Тимофеев А.В. Резонансные явления в колебаниях плазмы. М.: Физматлит, 2000. 1-е изд., 2009 2-е изд.
Федоров В.И. // Письма ЖЭТФ. 1980. Т. 6. С. 650.
Bornatici M., Engelmann F., Maroli C., Petrillo V. // Plasma Phys. 1981. V. 23. P. 89.
Lazzaro E., Ramponi G., Giruzzi G. // Phys. Fluids. 1982. V. 25. P. 1220.
Звонков А.В. // Физика плазмы. 1983. Т. 9. С. 547.
Тимофеев А.В. // УФН. 1973. Т. 110. С. 329.
Bernstein I.B. // Phys. Rev. 1958. V. 109. P. 10.
Litvak A.G., Suvorov E.V., Permitin G.V., Fraiman A.A. // Nuclear Fusion. 1979. V. 17. P. 659.
Alikaev V.V., Litvak A.G., Suvorov E.V., Fraiman A.A. // High Frequency Plasma Heating / Ed. A.G. Litvak. New York: AIP, 1991. Ch. 1. P. 1.
Tereshchenko M., Castejon F., Cappa A. TRUBA User Manual. Informes Técnicos CIEMAT No. 1134. Madrid: CIEMAT, 2008.
Prater R., Farina D., Gribov Yu., Harvey R.W., Ram A.K., Lin-Liu Y.-R., Poli E., Smirnov A.P., Volpe F., Wester-hof E., Zvonkov A. // Nuclear Fusion. 2008. V. 48. P. 035006.
Pereverzev G.V. // Phys. Plasmas. 1998. V. 5. P. 3529.
Balakin A.A., Balakina M.A., Westerhof E. // Nuclear Fusion. 2008. V. 48. P. 065003.
Балакин А.А. // Изв. вузов. Радиофизика. 2012. Т. 55. С. 521.
Shalashov A.G., Balakin A.A., Gospodchikov E.D., Khusainov T.A. // Phys. Plasmas. 2016. V. 23. P. 112504.
Гинзбург В.Л. Распространение электромагнитных волн в плазме. М.: Наука, 1967.
Батанов Г.М., Борзосеков В.Д., Колик Л.В., Конченков Е.М., Малахов Д.В., Петров А.Е., Сарксян К.А., Сахаров А.С., Скворцова Н.Н., Степахин В.Д., Харчев Н.К. // Физика плазмы. 2013. Т. 39. С. 987.
Westerhof E., Nielsen S.K., Oosterbeek J.W., Salewski M., De Baar M.R., Bongers W.A., Bürger A., Hennen B.A., Korsholm S.B., Leipold F., Moseev D., Stejner M., Thoen D.J. (the TEXTOR Team) // Phys. Rev. Lett. 2009. V. 103. P. 125001.
Nielsen S.K., Salewski M., Westerhof E., Bongers W., Korsholm S.B., Leipold F., Oosterbeek J.W., Moseev D., Stejner M. // Plasma Phys. Control. Fusion. 2013. V. 55. P. 115003.
Hansen S.K., Nielsen S.K., Stober J., Rasmussen J., Stejner M., Hoelzl M., Jensen T. // Nucl. Fusion. 2020. V. 60. P. 106008.
Сахаров А.С. // Физика плазмы. 2017. Т. 43. С. 903.
Шалашов А.Г., Господчиков Е.Д. // УФН. 2011. Т. 181. С. 151.
Shalashov A.G., Gospodchikov E.D. // Plasma Phys. Control. Fusion. 2010. V. 52. P. 025007.
Scott M.R. Invariant Imbedding and its Applications to Ordinary Differential Equations: an Introduction. London: Addison-Wesly, 1973.
Кляцкин В.И. Метод погружения в теории распространения волн. М.: Наука 1986.
Днестровский Ю.Н., Костомаров Д.П., Скрыд-лов Н.В. // ЖТФ. 1963. Т. 33. С. 922.
Шафранов В.Д. // Вопросы теории плазмы. Вып. 3 / Под ред. М.А. Леонтовича. М.: Госатомиздат, 1963. С. 129.
