Methodological Recommendations for the Creation of Sensor Measurement Systems for Respiratory Rate Monitoring Based on Photoplethysmographic Signal Processing

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

A methodical apparatus for creating sensor measurement systems for monitoring human respiration rate is proposed. It includes a method for estimating respiratory rate based on statistical analysis of photoplethysmographic signals (human pulse wave), a method for selecting priority regions for estimating respiratory rate, and a criterion for determining the required bracelet tension during measurements. The application of the respiratory rate estimation method involves calculating the Correntropy spectral density of the pulse wave signal. A distinctive feature of the method is the use of an algorithm for selecting the priority empirical mode of the Hilbert-Huang decomposition, which is most closely related to the respiratory rate. Experimental verification of the method showed that the mean value of the absolute error for 58.8% of the sample of calculated respiratory rate values did not exceed 1 breath/min, and the 95% confidence interval for the mean absolute error of the entire sample was [0.72–2.2] breaths/min.
