Email this article Cluster Self-Organization of Intermetallic Systems: Cluster Precursors K3, K4, K5, K7, and K8 for the Self-Assembly of Lu66Te24-mC90, Te4Lu28-oC32, Lu3(TeLu3)Lu2-hP9, and Lu4Te4-cF8 Crystal Structures
- Authors: Shevchenko V.Y.1, Ilyushin G.D.2
-
Affiliations:
- Grebenshchikov Institute of Silicate Chemistry, Russian Academy of Sciences
- Federal Research Center “Crystallography and Photonics”
- Issue: Vol 49, No 3 (2023)
- Pages: 223-234
- Section: Articles
- URL: https://journals.rcsi.science/0132-6651/article/view/139333
- DOI: https://doi.org/10.31857/S0132665122600947
- EDN: https://elibrary.ru/SLCWBB
- ID: 139333
Cite item
Open Access
Access granted
Subscription Access
Abstract
With the help of computer methods (ToposPro software package), a combinatorial topological analysis and modeling of the self-assembly of Lu4Te4-oF8 (Fm-3m, V = 211.0 Å3), Te4Lu28-oC32 (Cmcm, V = 908.3 Å3), Lu3(TeLu3)Lu2-hP9 (P-62m, V = 908.3 Å3), and Lu66Te24-mC90 (C12/m1, V = 2467.2 Å3) crystal structures are carried out. For the crystal structure of Lu4Te4-oF8, cluster precursors K8 = 0@Te4Lu4 with symmetry –43m; for Te4Lu28-oC32, tetrahedral cluster precursors K4 = 0@Lu4 and K4 = 0@TeLu3 with symmetry 2 and m; and for Lu3(TeLu3)Lu2, cluster precursors K7 = 0@Lu3(TeLu3) with symmetry 3m and spacers Lu are established. For the crystal structure of Lu66Te24-mC90, pyramid-shaped cluster precursors K5 = 0@Lu5 with symmetry 2, tetrahedra K4 = 0@Lu4 with symmetry 2, tetrahedra K4 = 0@TeLu3, and tetrahedra K4 = 0@Te2Lu2 are established, and rings K3 = 0@TeLu2 are involved in the formation of supraclusters-trimers. The symmetry and topological code of the processes of self-assembly of 3D structures from cluster precursors is reconstructed in the following form: primary chain → layer → framework.
About the authors
V. Ya. Shevchenko
Grebenshchikov Institute of Silicate Chemistry, Russian Academy of Sciences
Email: shevchenko@isc.nw.ru
199034, St. Petersburg, Russia
G. D. Ilyushin
Federal Research Center “Crystallography and Photonics”
Author for correspondence.
Email: gdilyushin@gmail.com
119333, Moscow, Russia
References
- Inorganic crystal structure database (ICSD). Fachinformationszentrum Karlsruhe (FIZ), Germany and US National Institute of Standard and Technology (NIST), USA.
- Villars P., Cenzual K. Pearson’s Crystal Data-Crystal Structure Database for Inorganic Compounds (PCDIC) ASM International: Materials Park, OH.
- Cannon J.F., Hall H.T. High-pressure, high-temperature syntheses of selected lanthanide-tellurium compounds // Inorganic Chemistry. 1970. V. 9. P. 1639–1643.
- Flahaut Jean, Laruelle Pierre, Pardo Marie Paule, Guittard Micheline.Les sulfures, seleniures et tellurures L2X3 de terres rares, d’yttrium et descandium orthorhombiques du type Sc2S3 // Bulletin de la Societe Chimique de France. 1965. V. 1965. P. 1399–1404.
- Hulliger F., Hull G.W.Jr. Superconductivity in rocksalt-type compounds // Solid State Communications. 1970. V. 8. P. 1379–1382.
- Chen Ling, Corbett J.D. Lu8 Te and Lu7 Te. Novel substitutional derivatives of lutetium metal // J. Am. Chem. Soc. 2003. V. 125. P. 7794–7795.
- Chen Ling, Xia Shengqing, Corbett J.D. Metal-rich chalcogenides. Synthesis, structure and bonding of the layered Lu11Te4. Comparison with the similar Sc8Te3 and Ti11Se4 // Inorg. Chem. 2005. V. 44. P. 3057–3062.
- Miller A.E., Daane A.H. The High-Temperature Allotropy of Some Heavy Rare-Earth Metals // Transactions of the Metallurgical Society of Aime. 1964. V. 230. P. 568–572.
- White J.G., Dismukes J.P. The Crystal Structure of Scandium Sesquitelluride // Inorg. Chem. 1965. V. 4. P. 1760–1763
- Assoud A., Kleinke H. The sesquitelluride Sc2Te3 // Acta Crystallogr., Sect. E: Struct. Rep. Online 2006. V. 62. P. i17–i18.
- Chai P., Corbett J.D. Two new compounds, β-ScTe and Y3Au2, and a reassessment of Y2Au. // Acta Crystallogr., Sect. C. V. 67. P. i53–i55.
- Maggard P.A., Corbett J.D. Sc2Te: A novel example of condensed metal polyhedra in a metal-rich but relatively electron-poor compound // Angewandte Chemie (Edition international). 1997. V. 36. P. 1974–1976.
- Maggard P.A., Corbett J.D. The synthesis, structure, and bonding of Sc8Te3 and Y8Te3. Cooperative matrix and bonding effects in the solid state // Inorg. Chem. 1998. V. 37. P. 814–820.
- Gupta S., Maggard P.A., Corbett J.D. A bismuth-stabilized metal-rich telluride Lu9 Bi ~ 1.0 Te ~ 1.0 -Synthesis and characterization // European J. Inorganic Chemistry. 2010. V. 18. P. 2620–2625.
- Pardo M.P., Flahaut J. Les tellurures superieurs des terres rares, de formules L2Te5 et LTe3 // Bulletin de la Societe Chimique de France. 1967. V. 1967. P. 3658–3664.
- Brixner L.H. Structure and electrical properties of some new rare earth arsenides, antimonides and tellurides // J. Inorganic and Nuclear Chemistry. 1960. V. 15. P. 199–201.
- Castro-Castro L.M., Chen Ling, Corbett J.D. Condensed rare-earth metal-rich tellurides. Extension of layered (Sc6PdTe2)-type compounds to yttrium and lutetium analogues and to Y7Te2, the limiting binary member // J. Solid State Chem. 2007. V. 180. P. 3172–3179.
- Weirich T.E., Ramlau R., Simon A., Hovmoeller S., Zou X.-D. A crystal structure determined to 0.02 Å accuracy by electron crystallography // Nature (London). 1996. V. 382. P. 144–146.
- Shevchenko V.Y., Blatov V.A., Ilyushin G.D. Structural Chemistry of Intermetallic Compounds: Geometric and Topological Analysis; Cluster Precursors K4, K6, and K21; and Self-Assembly of Crystal Structure Cs2Hg2-aP8, Cs2Hg4-oI12, and Cs10Hg38-tI48 // Glass Physics and Chemistry. 2022. V. 48. P. 155–162.
- Ilyushin G.D. Intermetallic compounds LikMn (M = Ag, Au, Pt, Pd, Ir, Rh): Geometrical and topological analysis, tetrahedral cluster precursors, and self-assembly of crystal structures // Crystallography Reports, 2020.V. 65. P. 202–210.
- Shevchenko V.Y., Blatov V.A., Ilyushin G.D. Cluster self-organization of intermetallic systems: New two-layer nanocluster precursors K64 = 0@8(Sn4Ba4)@56(Na4Sn52 and K47 = Na@Sn16@Na30 in the crystal structure of Na52Ba4Sn80-cF540 // Glass Physics and Chemistry. 2020. V. 46. P. 448–454.
- Ilyushin G.D. Intermetallic Compounds NakMn (M = K, Cs, Ba, Ag, Pt, Au, Zn, Bi, Sb): Geometrical and Topological Analysis, Cluster Precursors, and Self-Assembly of Crystal Structures // Crystallography Reports. 2020. V. 65. № 4. P. 539–545.
- Ilyushin G.D. Intermetallic Compounds KnMm (M = Ag, Au, As, Sb, Bi, Ge, Sn, Pb): Geometrical and Topological Analysis, Cluster Precursors, and Self-Assembly of Crystal Structures // Crystallography Reports. 2020. V. 65. № 7. P. 1095–1105.
- Blatov V.A., Shevchenko A.P., Proserpio D.M. Applied Topological Analysis of Crystal Structures with the Program Package ToposPro // Cryst. Growth Des. 2014. V. 14. № 7. P. 3576–3585.
