Experimental Study of the Heat Transfer at Compressible Gas Flow with a Favorable Pressure Gradient

N. A. Kiselev; Киселёв Н. А.; N. S. Malastovskii; Маластовский Н. С.; A. G. Zditovets; Здитовец А. Г.; Yu. A. Vinogradov; Виноградов Ю. А.

doi:10.31857/S0040364423040063

Experimental Study of the Heat Transfer at Compressible Gas Flow with a Favorable Pressure Gradient

Authors: Kiselev N.A.¹, Malastovskii N.S.¹^,2, Zditovets A.G.¹, Vinogradov Y.A.¹
Affiliations:
1. Institute of Mechanics, Moscow State University
2. Bauman Moscow State Technical University
Issue: Vol 61, No 4 (2023)
Pages: 578-587
Section: Articles
URL: https://journals.rcsi.science/0040-3644/article/view/232754
DOI: https://doi.org/10.31857/S0040364423040063
ID: 232754

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The parameters of heat transfer at compressible gas flow with a favorable pressure gradient have been experimentally studied. The heat transfer coefficients and the temperature of thermally insulated (adiabatic) wall are determined using the transient heat transfer method. To estimate the degree of flow laminarization, the results obtained are compared with the known dependences for the turbulent boundary layer developing on a plate in a zero-pressure gradient flow. Some regularities of the effect of flow acceleration on the heat transfer law are revealed for the studied configurations of supersonic nozzles.
