电邮这篇文章 Influence of the Moment of High Frequency Corona Discharge Initiation on the Combustion Development in a Hybrid Compression Engine
- 作者: Filimonova E.A.1, Dobrovolskaya A.S.1
-
隶属关系:
- Joint Institute for High Temperatures of Russian Academy of Sciences
- 期: 卷 61, 编号 3 (2023)
- 页面: 340-348
- 栏目: Articles
- URL: https://journals.rcsi.science/0040-3644/article/view/232626
- DOI: https://doi.org/10.31857/S0040364423030080
- ID: 232626
如何引用文章
开放存取
##reader.subscriptionAccessGranted##
订阅存取
详细
The work shows the dependence of the moment of the discharge-activated zone ignition and the moment of self-ignition of the fuel mixture in the region ahead of the combustion wave front on two parameters: the crankshaft rotation angle at which the discharge was initiated and the specific energy input into the streamer channel. It is shown the necessity to take into account the change in pressure in the cylinder due to the movement of the piston in order to more accurately determine the optimal ignition limits of the activated zone and the occurrence of self-ignition. When modeling, the inhomogeneous formation of chemically active particles associated with the streamer and multi-pulse nature of the discharge was taken into account.
作者简介
E. Filimonova
Joint Institute for High Temperatures of Russian Academy of Sciences
Email: helfil@mail.ru
Moscow, Russia
A. Dobrovolskaya
Joint Institute for High Temperatures of Russian Academy of Sciences
编辑信件的主要联系方式.
Email: helfil@mail.ru
Moscow, Russia
参考
- Dahms R., Felsch C., Rohl O., Peters N. Detailed Chemistry Flamelet Modeling of Mixed Mode Combustion in Spark-Assisted HCCI Engines // Proc. Combust. Inst. 2011. V. 33. P. 3023.
- Saxena S., Bedoya I.D. Fundamental Phenomena Affecting Low Temperature Combustion and HCCI Engines, High Load Limits and Strategies for Extending These Limits // Prog. Energy Combust. Sci. 2013. V. 39. P. 457.
- Persson H., Johansson B., Remón A. The Effect of Swirl on Spark Assisted Compression Ignition (SACI) // JSAE. 2007. 20077167 (SAE 2007-01-1856).
- Schenk A., Rixecker G., Bohne S. Results from Gasoline and CNG Engine Tests with the Corona Ignition System EcoFlash // 3rd Laser Ignition Conf. Proc. Argonne, US, 2015. W4A.4.
- Auzas F., Tardiveau P., Puech P., Makarov M., Agneray A. Heating Effects of a Non-Equilibrium RF Corona Discharge in Atmospheric Air // J. Phys. D: Appl. Phys. 2010. V. 43. 495204.
- Mariani A., Foucher F. Radio Frequency Spark Plug: An Ignition System for Modern Internal Combustion Engines // Appl. Energy. 2014. V. 122. P. 151.
- Discepoli G., Cruccolini V., Ricci F., Giuseppe A.D., Papi S., Grimaldi C.N. Experimental Characterisation of the Thermal Energy Released by a Radio Frequency Corona Igniter in Nitrogen and Air // Appl. Energy. 2020. V. 263. 114617.
- Yu X., Wang L., Yu S., Wang M., Zheng M. Flame Kernel Development with Radio Frequency Oscillating Plasma Ignition // PSST. 2022. V. 31. 055004.
- Wei H., Chen C., Shu G., Liang X., Zhou L. Pressure Wave Evolution During Two Hotspots Autoignition within End-gas Region under Internal Combustion Engine-Relevant Conditions // Combust. Flame. 2018. V. 189. P. 142.
- Terashima H., Koshi M. Mechanisms of Strong Pressure Wave Generation in End-gas Autoignition During Knocking Combustion // Combust. Flame. 2015. V. 162. P. 1944.
- Pan J., Shu G., Zhao P., Wei H., Chen Z. Interactions of Flame Propagation, Auto-ignition and Pressure Wave During Knocking Combustion // Combust. Flame. 2016. V. 164. P. 319.
- Киверин А.Д., Смыгалина А.Е. Механизмы развития интенсивных динамических процессов при сжигании водорода в камерах сгорания ДВС // ТВТ. 2022. Т. 60. № 1. С. 103.
- Filimonova E., Bocharov A., Bityurin V. Influence of a Non-equilibrium Discharge Impact on the Low Temperature Combustion Stage in the HCCI Engine // Fuel. 2018. V. 228. P. 309.
- Filimonova E.A., Dobrovolskaya A.S., Bocharov A.N., Bityurin V.A., Naidis G.V. Formation of Combustion Wave in Lean Propane-Air Mixture with a Non-Uniform Chemical Reactivity Initiated by Nanosecond Streamer Discharges in the HCCI Engine // Combust. Flame. 2020. V. 215. P. 401.
- Dobrovolskaya A.S., Filimonova E.A., Bityurin V.A., Bocharov A.N. Role of Pressure Waves in the Heating of the End-Gas in HCCI Engine with Activation by Pulsed Corona Discharge // J. Phys.: Conf. Ser. 2021. V. 2100(1). 012016.
- Филимонова Е.А. Кинетика процессов горения, конверсии оксидов азота и углеводородов, стимулированных наносекундными разрядами. Дис. … докт. физ.-мат. наук. М.: ОИВТ РАН, 2021. 337 с.
- Битюрин В.А., Бочаров А.Н. Магнитогидродинамическое взаимодействие при обтекании затупленного тела гиперзвуковым воздушным потоком // МЖГ. 2006. № 5. С. 188.
- Filimonova E.A. Discharge Effect on the Negative Temperature Coefficient Behaviour and Multistage Ignition in C3H8‒Air Mixture // J. Phys. D: Appl. Phys. 2015. V. 48. 015201.
- Dobrovolskaya A., Filimonova E., Bityurin V., Bocharov A., Klyuchnikov N. Different Numerical Approaches for Simulation of Combustion Wave Initiation by Electrical Discharge // AIP Conf. Proc. 2018. V. 1978(1). 470074.
- Железняк М.Б., Филимонова Е.А. Моделирование газофазного химического реактора на основе импульсного стримерного разряда для удаления токсичных примесей. Ч. I // ТВТ. 1998. Т. 36. № 3. С. 374.
- Железняк М.Б., Филимонова Е.А. Моделирование газофазного химического реактора на основе импульсного стримерного разряда для удаления токсичных примесей // ТВТ. 1998. Т. 36. № 4. С. 557.
- Babaeva N.Yu., Naidis G.V. Two-Dimensional Modelling of Positive Streamer Dynamics in Non-Uniform Electric Fields in Air // J. Phys. D: Appl. Phys. 1996. V. 29. P. 2423.
- Pan J., Shu G., Wei H. Interaction of Flame Propagation and Pressure Waves During Knocking Combustion in Spark-ignition Engines // Combust. Sci. Technol. 2014. V. 186 (2). P. 192.
- Yu H., Chen Zh. End-gas Autoignition and Detonation Development in a Closed Chamber // Combust. Flame. 2015. V. 162. P. 4102.
