Steam Reforming of Ethane in a Membrane Reactor with a Nickel Catalyst at High Temperatures

Authors: Babak V.N.¹, Didenko L.P.¹, Sementsova L.A.¹, Kvurt Y.P.²
Affiliations:
1. Federal Research Center of Problems of Chemical Physics and Medicinal Chemistry, Russian Academy of Sciences
2. Федеральный исследовательский центр проблем химической физики и медицинской химии РАН
Issue: Vol 57, No 3 (2023)
Pages: 292-308
Section: Articles
URL: https://journals.rcsi.science/0040-3571/article/view/138467
DOI: https://doi.org/10.31857/S0040357123030016
EDN: https://elibrary.ru/RLNNDC
ID: 138467

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

A model of steam reforming of pure ethane in a membrane catalytic reactor is proposed. The working elements of the reactor are cylindrical chambers, between which a hydrogen-selective palladium foil is placed. The upper chamber is vacuumized, and the lower one contains a nickel catalyst. In the case of uniform feed of the feedstock (С2Н6 and Н2О) along the perimeter of the lower chamber, the problem is reduced to finding the average flows of С2Н6, СН4, Н2О, СО, СО2, and Н2 by solving a system of nonlinear ordinary differential equations. The studies are carried out in the temperature range of 700–1000 K at acceptable steam/ethane input flow ratios of more than four. The optimal conditions for the process, at which the hydrogen yield is 100%, are found. It is proved that under these conditions and a fixed temperature, the maximum hydrogen flow through the membrane is observed at the minimum permissible ratio of the steam and ethane input flows, equal to four. Comparison of the calculations with the experimental data confirm the assumption of the existence of two sections in the lower chamber (short initial and main sections).
