Artificial Magnetic Conductors Based on Frequency Selective Surfaces
- Authors: Kazantsev Y.N.1, D’yakonova O.A.1
-
Affiliations:
- Kotelnikov Institute of Radioengineering and Electronics, Fryazino Branch, Russian Academy of Sciences
- Issue: Vol 68, No 7 (2023)
- Pages: 627-631
- Section: ЭЛЕКТРОДИНАМИКА И РАСПРОСТРАНЕНИЕ РАДИОВОЛН
- URL: https://journals.rcsi.science/0033-8494/article/view/138301
- DOI: https://doi.org/10.31857/S0033849423060062
- EDN: https://elibrary.ru/XMDXPR
- ID: 138301
Cite item
Abstract
New band-passing frequency-selective surfaces (FSSs) are proposed and investigated. Formulas for calculating the modulus and phase of the reflection coefficient of artificial magnetic conductors are obtained based on the proposed FSSs. The comparison of the results of electrodynamic modeling and calculation by formulas is carried out. The possibility of expanding the operating frequency band is shown.
About the authors
Yu. N. Kazantsev
Kotelnikov Institute of Radioengineering and Electronics, Fryazino Branch, Russian Academy of Sciences
Email: yukazantsev@mail.ru
Fryazino, Moscow oblast, 141190 Russia
O. A. D’yakonova
Kotelnikov Institute of Radioengineering and Electronics, Fryazino Branch, Russian Academy of Sciences
Author for correspondence.
Email: yukazantsev@mail.ru
Fryazino, Moscow oblast, 141190 Russia
References
- Qian Y., Radisic V., Itoh T. // Proc. 1997 Int. Asia-Pacific Microwave Conf. (APMC). Hong-Kong. 2–5 Dec. 1997. N.Y.: IEEE, 1997. V. 2. P. 585.
- Qian Y., Yang F-R., Itoh T. // Proc. 1998 Int. Asia-Pacific Microwave Conf. (APMC) Yokohama. 08–11 Dec. Tokyo: IEICE, 1998. P. 589.
- Yang F-R., Qian Y., Coccioli R., Itoh T. // IEEE Trans. 1998. V. MGW-8. P. 372.
- Yang F-R., Qian Y., Itoh T. // Proc. 1998 Int. Asia-Pacific Microwave Conf. (APMC) Yokohama. 08–11 Dec. Tokyo: IEICE, 1998. P. 593.
- Yang F-R., Coccioli R., Qian Y., Itoh T. // Dig. 1999 IEEE Antennas and Propagation Soc. Int. Symp. Orlando. 11–16 Jul. N.Y.: IEEE, 1999. V. 3. P. 1920.
- Coccioli R., Yang F-R., Ma R. P., Itoh T. // IEEE Trans. 1999. V. MTT-47. № 11. P. 2123.
- Yang F-R., Qian Y., Itoh T. // Dig. 1999 IEEE Microwave Theory and Techniques Soc. (MTT-S) Int. Microwave Symp. Anaheim. 13–19 Jun. N.Y.: IEEE, 1999. V. 3. P. 919.
- Yang F-R., Ma R.P., Qian Y., Itoh T. // IEEE Trans. 1999. V. MTT-47. № 8. P. 1509.
- Yang F-R., Coccioli R., Qian Y., Itoh T. // Dig. 2000 IEEE Microwave Theory and Techniques Soc. (MTT-S) Int. Microwave Symp. 11–16 Jun. Boston. N.Y.: IEEE, 2000. V. 3. P. 1529.
- Chang Q.C., Qian Y., Itoh T. // Progress in Electromagnetics Research. PIER. 2003. V. 41. P. 211.
- Sievenpiper D., Zhang L., Broas R.J. et al. // IEEE Trans. 1999. V. MTT-47. № 11. P. 2059.
- Broas R.J., Sievenpiper D., Yablonovitch E. // IEEE Trans. 2001. V. MTT-49. № 7. P. 1262.
- Broas R.J., Sievenpiper D., Yablonovitch E. // IEEE Trans. 2005. V. AP-53. № 4. P. 1377.
- Hiranandani M.A., Yakovlev A.B., Kishk A.A. // IEE Proc. Microw. Antennas Propag. 2006. V. 153. № 5. P. 487.
- Kern D.J., Werner D.H., Monorchio A. et al. // IEEE Trans. 2005. V. AP-53. № 1. P. 8.
- Sohn J.R., Kim K.Y., Lee J.-H., Tae H.-S. // Progress in Electromagnetics Research (PIER). 2006. V. 61. P. 27.
- Казанцев Ю.Н., Крафтмахер Г.А., Мальцев В.П. // РЭ. 2019. Т. 64. № 9. С. 874.
- Дьяконова О.А., Казанцев Ю.Н. // Журн. радиоэлектроники. 2018. № 8. http://jre.cplire.ru/jre/ aug18/10/text.pdf.
- Бреховских Л.М. Волны в слоистых средах. М.: Наука, 1973.
