On the Orbital Stability of Pendulum Periodic Motions of a Heavy Rigid Body with a Fixed Point, the Main Moments of Inertia of which are in the Ratio 1 : 4 : 1
- Authors: Bardin B.S.1, Maksimov B.A.1
-
Affiliations:
- Moscow Aviation Institute
- Issue: Vol 87, No 5 (2023)
- Pages: 784-800
- Section: Articles
- URL: https://journals.rcsi.science/0032-8235/article/view/232511
- DOI: https://doi.org/10.31857/S0032823523050041
- EDN: https://elibrary.ru/QHQNGW
- ID: 232511
Cite item
Open Access
Access granted
Subscription Access
Abstract
The motion of a heavy rigid body with a fixed point in a uniform gravitational field is considered. It is assumed that the main moments of inertia of the body for the fixed point satisfy the condition of D.N. Goryachev–S.A. Chaplygin, i.e., they are in the ratio 1 : 4 : 1. In contrast to the integrable case of D.N. Goryachev–S.A. Chaplygin, no additional restrictions are imposed on the position of the center of mass of the body.
The problem of orbital stability of pendulum periodic motions of the body is investigated. In the neighborhood of periodic motions, local variables are introduced and equations of perturbed motion are obtained. On the basis of a linear analysis of stability, the orbital instability of pendulum rotations for all values of the parameters has been concluded. It has been established that, depending on the values of the parameters, pendulum oscillations can be both orbitally unstable and orbitally stable in a linear approximation. For pendulum oscillations that are stable in the linear approximation, based on the methods of KAM theory, a nonlinear analysis is performed and rigorous conclusions about the orbital stability are obtained.
About the authors
B. S. Bardin
Moscow Aviation Institute
Author for correspondence.
Email: bsbardin@yandex.ru
Russia, Moscow
B. A. Maksimov
Moscow Aviation Institute
Author for correspondence.
Email: badmamaksimov1@gmail.com
Russia, Moscow
References
- Markeev A.P. The stability of the plane motions of a rigid body in the Kovalevskaya case // JAMM, 2001, vol. 65, no. 1, pp. 51–58.
- Markeev A.P. Medvedev S.V., Chekhovskaya T.N. To the problem of stability of pendulum-like vibrations of a rigid body in Kovalevskaya’s case // Mech. Solids, vol. 38, no. 1, pp. 1–6.
- Irtegov V.D. The Stability of the pendulum-like oscillations of a Kovalevskaya gyroscope // Tr. Kazan. Aviats. Inst. Matem. i Mekh., 1968, vol. 97, pp. 38–40 (in Russian)
- Bryum A.Z. A study of orbital stability by means of first integrals // JAMM, 1989, vol. 53, no. 6, pp. 689–695.
- Bryum A.Z., Savchenko A.Ya. On the orbital stability of a periodic solution of the equations of motion of a Kovalevskaya gyroscope // JAMM, 1986, vol. 50, no. 6, pp. 748–753.
- Bardin B.S. Stability problem for pendulum-type motions of a rigid body in the Goryachev–Chaplygin case // Mech. Solids, 2007, vol. 42, no. 2, pp. 177–183.
- Bardin B.S. On a method of introducing local coordinates in the problem of the orbital stability of planar periodic motions of a rigid body // Rus. J. Nonlin. Dyn., 2020, vol. 16, no. 4, pp. 581–594.
- Markeev A.P. The pendulum-like motions of a rigid body in the Goryachev–Chaplygin case // JAMM, 2004, vol. 68, no. 2, pp. 249–258.
- Bardin B.S., Rudenko T.V., Savin A.A. On the orbital stability of planar periodic motions of a rigid body in the Bobylev–Steklov case // R&C Dyn., 2012, vol. 17, no. 6, pp. 533–546.
- Bardin B.S. Local coordinates in problem of the orbital stability of pendulum-like oscillations of a heavy rigid body in the Bobylev–Steklov case // J. Phys.: Conf. Ser., Bristol, 2021, art. no. 012016, pp. 1–10.
- Yehia H.M., Hassan S.Z., Shaheen M.E. On the orbital stability of the motion of a rigid body in the case of Bobylev–Steklov // Nonlin. Dyn., 2015, vol. 80, no. 3, pp. 1173–1185.
- Bardin B.S., Savin A.A. On the orbital stability of pendulum-like oscillations and rotations of a symmetric rigid body with a fixed point // R&C Dyn., 2012, vol. 17, no. 3–4, pp. 243–257.
- Bardin B.S., Savin A.A. The stability of the plane periodic motions of a symmetrical rigid body with a fixed point // JAMM, 2013, vol. 77, no. 6, pp. 806–821.
- Liapunov A.M. The General Problem of the Stability of Motion. Moscow; Leningrad: GITTL, 1950. 471 p. (in Russian)
- Markeev A.P. Linear Hamiltonian Systems and Some Problems of Stability of the Satellite Center of Mass. Izhevsk: R&C Dyn.; Inst. Comput. Res., 2009. 395 p. (in Russian)
- Giacaglia G.E.O. Perturbation Methods in Non-Linear Systems. N.Y.: Springer, 1972. 369 p.
- Markeev A.P. Libration Points in Celestial Mechanics and Space Dynamics. Moscow: Nauka, 1978. 312 p. (in Russian)
- Arnold V.I. Mathematical Methods of Classical Mechanics. N.Y.: Springer, 1989. 518 p.
- Siegel C., Moser J. Lectures on Celestial Mechanics. N.Y.: Springer, 1971. xii+290 p.
- Ivanov A.P., Sokol’skii A.G. On the stability of a nonautonomous Hamiltonian system under a parametric resonance of essential type // JAMM, 1980, vol. 44, no. 6, pp. 687–691.
- Markeev A.P. Stability of equilibrium states of Hamiltonian systems: a method of investigation // Mech. Solids, 2004, vol. 39, no. 6, pp. 1–8.
- Bardin B.S., Chekina E.A., Chekin A.M. On the stability of planar resonant rotation of a satellite in an elliptic orbit // R&C Dyn., 2015, vol. 20, no. 1, pp. 63–73.
