A Low-Noise Fiber Phase-Sensitive Optical Time-Domain Reflectometer for Seismology Application

A. E. Alekseev; Алексеев А. Э.; B. G. Gorshkov; Горшков Б. Г.; D. A.  Il’inskii; Ильинский Д. А.; V. T. Potapov; Потапов В. Т.; D. E. Simikin; Симикин Д. Е.; M. A. Taranov; Таранов М. А.

doi:10.31857/S0032816223050014

A Low-Noise Fiber Phase-Sensitive Optical Time-Domain Reflectometer for Seismology Application

Authors: Alekseev A.E.¹, Gorshkov B.G.², Il’inskii D.A.³, Potapov V.T.¹, Simikin D.E.¹^,4, Taranov M.A.¹^,4
Affiliations:
1. Fryazino Branch of Kotel’nikov Institute of Radio Engineering and Electronics, Russian Academy of Sciences
2. Prokhorov General Physics Institute, Russian Academy of Sciences
3. Shirshov Institute of Oceanology, Russian Academy of Sciences
4. OOO Petrofibre
Issue: No 5 (2023)
Pages: 134-140
Section: ФИЗИЧЕСКИЕ ПРИБОРЫ ДЛЯ ЭКОЛОГИИ, МЕДИЦИНЫ, БИОЛОГИИ
URL: https://journals.rcsi.science/0032-8162/article/view/138509
DOI: https://doi.org/10.31857/S0032816223050014
EDN: https://elibrary.ru/ZHMNRT
ID: 138509

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

A fiber phase-sensitive optical time-domain reflectometer (a distributed acoustic sensor) with a low-noise output signal in the frequency range of 0.01−1 Hz is proposed for seismology applications. The sensor architecture is based on an unbalanced Mach−Zehnder interferometer, which is used to form a dual-pulse probe signal with required phases of its components and to stabilize the frequency of the laser source in the feedback circuit. The low noise level of the output signal is achieved in the proposed circuit by compensating for the difference in the optical paths of the dual-pulse probe signal fields scattered by different fiber sections. The applicability of the proposed circuit has been experimentally demonstrated by detecting a remote earthquake using a fiber-optic cable located at the bottom of the Black Sea.
