Method for Increasing the Signal-to-Noise Ratio of Rayleigh Back-Scattered Radiation Registered by a Frequency Domain Optical Reflectometer Using Two-Stage Erbium Amplification
- Authors: Belokrylov M.E.1, Claude D.1, Konstantinov Y.A.1, Karnaushkin P.V.1,2, Ovchinnikov K.A.3, Krishtop V.V.2,3,4, Gilev D.G.2,3, Barkov F.L.1, Ponomarev R.S.1,2
-
Affiliations:
- Perm Federal Research Center, Ural Branch, Russian Academy of Sciences
- Perm State University
- Perm Research and Production Instrument-Making Company
- Perm National Research Polytechnic University
- Issue: No 5 (2023)
- Pages: 56-63
- Section: ОБЩАЯ ЭКСПЕРИМЕНТАЛЬНАЯ ТЕХНИКА
- URL: https://journals.rcsi.science/0032-8162/article/view/138472
- DOI: https://doi.org/10.31857/S0032816223050178
- EDN: https://elibrary.ru/ZUWZBO
- ID: 138472
Cite item
Abstract
Simple measures to improve the signal-to-noise ratio of optical frequency domain reflectometer (OFDR) readings are described. After applying a two-stage optical amplification of the backscattered signal, as well as eliminating the source of spurious reflections, it was possible to increase the signal-to-noise ratio of the frequency domain trace from 8 to 19 dB. This technique can be applied in fiber optic sensors and metrology of fiber optic and integrated optical elements.
