Breaking of the Cubic Symmetry in Millimeter-Size SrTiO3 Crystals: ESR Manifestations

B. F. Gabbasov; Габбасов Б. Ф.; I. N. Gracheva; Грачева И. Н.; S. I. Nikitin; Никитин С. И.; V. A. Trepakov; Трепаков В. А.; R. V. Yusupov; Юсупов Р. В.

doi:10.31857/S0023476123600556

Breaking of the Cubic Symmetry in Millimeter-Size SrTiO3 Crystals: ESR Manifestations

Authors: Gabbasov B.F.¹, Gracheva I.N.¹, Nikitin S.I.¹, Trepakov V.A.², Yusupov R.V.¹
Affiliations:
1. Kazan Federal University, 420008, Kazan, Russia
2. Ioffe Institute, Russian Academy of Sciences, 194021, St. Petersburg, Russia
Issue: Vol 68, No 5 (2023)
Pages: 709-721
Section: REAL STRUCTURE OF CRYSTALS
URL: https://journals.rcsi.science/0023-4761/article/view/137405
DOI: https://doi.org/10.31857/S0023476123600556
EDN: https://elibrary.ru/DOJDMV
ID: 137405

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The found effect of lowering the symmetry of the crystal structure of thin (less than 1 mm) plates and bars of strontium titanate (SrTiO3) single crystals is discussed. This symmetry lowering manifests itself in the electron spin resonance (ESR) spectra of impurity centers (Fe³⁺ and Mn⁴⁺ ions, used as paramagnetic probes). It is shown that symmetry lowering is observed at temperatures T > 105 K, which generally correspond to the cubic phase of SrTiO3; it leads to the formation of a tetragonal nonpolar structure, differing from the antiferrodistortive (AFD) phase D4ℎ18, which is characteristic of strontium titanate at T < 105 K and was not observed previously in SrTiO3. The factors determining the distortion value are found to be the geometry and ratio of sample sizes, surface finishing quality, and crystallographic orientation of plates.

References

Gastiasoro M.N., Rouhman J., Fernandes R.M. // Ann. Phys. 2020. V. 417. P. 168107. https://doi.org/10.1016/j.aop.2020.168107
Kiselov D.E., Feigelman M.V. // Phys. Rev. B. 2021. V. 104. P. 220506. https://doi.org/10.1103/PhysRevB.104.L220506
Makarova M.V., Prokhorov A., Stupakov A. et al. // Crystals. 2022. V. 12. P. 1275. https://doi.org/10.3390/cryst12091275
Габбасов Б.Ф., Родионов А.А., Никитин С.И. и др. // ФТТ. 2021. Т. 63. С. 2.
Gabbasov B.F., Gracheva I.N., Rodionov A.A. et al. // Europhys. Lett. 2021. V. 133. P. 37002. https://doi.org/10.1209/0295-5075/133/37002
Unoki H., Sakudo T. // J. Phys. Soc. Jpn. 1967. V. 23. P. 546. https://doi.org/10.1143/JPSJ.23.546
Rimai L., DeMars G. // Phys. Rev. 1962. V. 127. P. 702. https://doi.org/10.1103/PhysRev.127.702
Müller K.A. // Phys. Rev. Lett. 1959. V. 2. P. 341. https://doi.org/10.1103/PhysRevLett.2.341
Müller K.A. “Paramagnetische Resonanz von Fe3+ in SrTiO3 Einkristallen” Ph.D. dissertation. Basel, 1958. https://doi.org/10.3929/ethz-a-000104546
Abragam A. Electron Paramagnetic Resonance of Transition Ions. Oxford: Oxford Univ. Press, 2012. 911 p.
Gabbasov B.F., Gracheva I.N., Nikitin S.I. et al. // Magn. Reson. Solids. 2018. V. 20 (2). Art. 18201.
Ham F.S. // Phys. Rev. 1965. V. 138. P. 1727. https://doi.org/10.1103/PhysRev.138.A1727
Aso K. // Jpn. J. Appl. Phys. V. 15 1976. P. 1243. https://doi.org/10.1143/JJAP.15.1243
Глинчук М.Д. Электрические эффекты в радиоспектроскопии. Электронный парамагнитный, двойной электронно-ядерный и параэлектрический резонансы. М.: Наука, 1981. 336 с.
Mims W.B. The Linear Electric Field Effect in Paramagnetic Resonance. Oxford: Clarendon Press, 1976. 339 p.
Каганов М.И., Омельянчук А.Н. // ЖЭТФ. 1971. Т. 61. С. 1679.
Zhou Y., Rabe K.M., Vanderbilt D. // Phys. Rev. B. 2015. V. 92. Art. 041102. https://doi.org/10.1103/PhysRevB.92.041102
Vanderbilt D. // Surf. Rev. Lett. 1997. V. 4. P. 811. https://doi.org/10.1142/S0218625X9700081X
Okazaki A., Ohama N., Muller K.A. // J. Phys. C: Solid State Phys. 1986. V. 19. P. 5019. https://doi.org/10.1088/0022-3719/19/25/019
Höchli U.T., Rohrer H. // Phys. Rev. Lett. 1982. V. 48. P. 188. https://doi.org/10.1103/PhysRevLett.48.188
