Comparative Analysis of Structural Variant Callers on the Short-Read Whole-Genome Sequencing Data

A. A. Mkrtchian; Мкртчян А. А.; S. M. Yudin; Юдин С. М.; A. A. Keskinov; Кескинов А. А.; V. S. Yudin; Юдин В. С.; T. A. Shpakova; Шпакова Т. А.; L. V. Frolova; Фролова Л. В.; E. A. Snigir; Снигирь Е. А.; A. P. Sergeev; Сергеев А. П.; D. V. Svetlichny; Светличный Д. В.; M. N. Pilipenko; Пилипенко М. Н.; A. A. Ivashechkin; Ивашечкин А. А.; P. U. Zemsky; Земский П. Ю.; S. I. Mitrofanov; Митрофанов С. И.; P. G. Kazakova; Казакова П. Г.; K. S. Grammatikati; Грамматикати К. С.; V. I. Skvortsova; Скворцова В. И.

doi:10.31857/S0016675823060115

Comparative Analysis of Structural Variant Callers on the Short-Read Whole-Genome Sequencing Data

Authors: Mkrtchian A.A.¹, Yudin S.M.¹, Keskinov A.A.¹, Yudin V.S.¹, Shpakova T.A.¹, Frolova L.V.¹, Snigir E.A.¹, Sergeev A.P.¹, Svetlichny D.V.¹, Pilipenko M.N.¹, Ivashechkin .A.¹, Zemsky P.U.¹, Mitrofanov S.I.¹, Kazakova P.G.¹, Grammatikati K.S.¹, Skvortsova V.I.²
Affiliations:
1. Federal State Budgetary Institution “Centre for Strategic Planning and Management of Biomedical Health Risks” of the Federal Medical Biological Agency
2. The Federal Medical Biological Agency of Russia
Issue: Vol 59, No 6 (2023)
Pages: 687-707
Section: МАТЕМАТИЧЕСКИЕ МОДЕЛИ И МЕТОДЫ
URL: https://journals.rcsi.science/0016-6758/article/view/134609
DOI: https://doi.org/10.31857/S0016675823060115
EDN: https://elibrary.ru/SUEMFU
ID: 134609

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

In this study three structural variant callers (Manta, Smoove, Delly) were analysed on the whole-genome sequencing data using four different alignment algorithms: DRAGEN, GDC DNA-Seq Alignment Workflow, GDC DNA-Seq Alignment Workflow + GDC DNA-Seq Co-Cleaning Workflow, NovoAlign, different lengths of raw reads: 2 × 150 bp and 2 × 250 bp, different mean genome coverage values. Results were compared to etalon results of GIAB team. Structural variants validation was hold also with Sanger sequencing. Structural variants deletions and insertions as it turned out were best determined with Manta tool. We’ve got 89–96% of accuracy and 59–70% of sensitivity for analysed deletions, and also 96–99% of accuracy and 15–36% of sensitivity for insertions. Smoove and Delly showed less accurate and sensitive results (Smoove: 91–95% of accuracy and 8–54% of sensitivity for deletions, Delly: 78–87% of accuracy and 31–66% of sensitivity for deletions, 99–100% of accuracy and 1–13% of sensitivity for insertions). Simultaneous using of two or even three structural variant callers didn’t give a rise of accuracy and sensitivity for deletions. Analysis showed that accuracy and sensitivity of structural variant callers rise with the rising of mean genome coverage value, increasing of reads length from 150 to 250 bp influence in to varying degrees on the accuracy and sensitivity of individual tools. Another inference of this study was that accuracy of structural variants callers vary depends on structural variants size range. For example, Manta finds better deletions in the range from 200 and more bp, Delly – from 1000 to 10 000 bp, Smoove – from 200 to 10 000 bp.

Keywords

structural variants, WGS, short-read sequencing, alignment, GIAB.

References

Pang A.W., MacDonald J.R., Pinto D. et al. Towards a comprehensive structural variation map of an individual human genome // Genome Biol. 2010. V. 11. № 5. P. R52. https://doi.org/10.1186/gb-2010-11-5-r52
The International HapMap Consortium. The international hapmap project // Nature. 2003. P. 789–796. https://doi.org/10.1038/nature02168
Sudmant P.H., Rausch T., Gardner E.J. et al. An integrated map of structural variation in 2,504 human genomes: 7571 // Nature. 2015. V. 526. № 7571. P. 75–81. https://doi.org/10.1038/nature15394
Pös O., Radvanszky J., Buglyo G. et al. DNA copy number variation: Main characteristics, evolutionary significance, and pathological aspects // Biomed. J. 2021. V. 44. № 5. P. 548–559. https://doi.org/10.1016/j.bj.2021.02.003
Alkan C., Coe B.P., Eichler E.E. Genome structural variation discovery and genotyping // Nat. Rev. Genet. 2011. V. 12. № 5. P. 363–367. https://doi.org/10.1038%2Fnrg2958
Mahmoud M., Gobet N., Cruz-Davalos D.I. et al. Structural variant calling: the long and the short of it // Genome Biol. 2019. V. 20. № 1. P. 246. https://doi.org/10.1186/s13059-019-1828-7
Carvalho C.M., Lupski J.R. Mechanisms underlying structural variant formation in genomic disorders // Nat. Rev. Genet. 2016. V. 17. № 4. P. 224–238. https://doi.org/10.1038/nrg.2015.25
Sedlazeck F.J., Lee H., Darby C.A. et al. Piercing the dark matter: bioinformatics of long-range sequencing and mapping // Nat. Rev. Genet. 2018. V. 19. № 6. P. 329–346. https://doi.org/10.1038/s41576-018-0003-4
Collins R.L., Brand H., Karczewski K.J. et al. A structural variation reference for medical and population genetics // Nature. 2021. V. 581. P. 444–451. https://doi.org/10.1038/s41586-020-2287-8
Weischenfeldt J., Symmons O., Spitz F. et al. Phenotypic impact of genomic structural variation: Insights from and for human disease // Nat. Rev. Genet. 2013. V. 14. № 2. P. 125–138. https://doi.org/10.1038/nrg3373
Stankiewicz P., Lupski J. Structural variation in the human genome and its role in disease // Annu. Rev. Med. 2010. V. 61. P. 437–455. https://doi.org/10.1146/annurev-med-100708-204735
Schüle B., McFarland K.N., Lee K. et al. Parkinson’s disease associated with pure ATXN10 repeat expansion // NPJ Parkinson’s Disease. 2017. V. 3. P. 27. https://doi.org/10.1038/s41531-017-0029-x
Yeh Y.C., Ho H.L., Wu Y.C. et al. AKT1 internal tandem duplications and point mutations are the genetic hallmarks of sclerosing pneumocytoma // Mod. Pathol. 2020. V. 33. № 3. P. 391–403. https://doi.org/10.1038/s41379-019-0357-y
Schütte J., Reusch J., Khandanpour C. et al. Structural variants as a basis for targeted therapies in hematological malignancies // Front. Oncol. 2019. V. 9. P. 839. https://doi.org/10.3389%2Ffonc.2019.00839
Ewing A., Meynert A., Churchman M. et al. Structural variants at the BRCA1/2 loci are a common source of homologous repair deficiency in high-grade serous ovarian carcinoma // Clin. Cancer Res. V. 27. № 11. P. 3201–3214. https://doi.org/10.1158/1078-0432.ccr-20-4068
Malhotra D., Sebat J. CNVs: Harbingers of a rare variant revolution in psychiatric genetics // Cell. 2012. V. 148. № 6. P. 1223–1241. https://doi.org/10.1016%2Fj.cell.2012.02.039
Huse K., Taudien S., Groth M. et al. Genetic variants of the copy number polymorphic β-defensin locus are associated with sporadic prostate cancer // Tumor Biol. 2008. V. 29. № 2. P. 83–92. https://doi.org/10.1159/000135688
Wellcome Trust Case Control Consortium. Genome-wide association study of CNVs in 16,000 cases of eight common diseases and 3,000 shared controls // Nature. 2010. V. 464. P. 713–720. https://doi.org/10.1038/nature08979
Fanciulli M., Norsworthy P.J., Petretto E. et al. FCGR3B copy number variation is associated with susceptibility to systemic, but not organ-specific, autoimmunity // Nat. Genet. 2007. V. 39. № 6. P. 721–723. https://doi.org/10.1038/ng2046
Fellermann K., Stange D.E., Schaeffeler E. et al. A chromosome 8 gene-cluster polymorphism with low human beta-defensin 2 gene copy number predisposes to crohn disease of the colon // Am. J. Hum. Genet. 2006. V. 79. № 3. P. 439–448. https://doi.org/10.1086/505915
Hollox E.J., Huffmeier U., Zeeuwen P.L. et al. Psoriasis is associated with increased β-defensin genomic copy number // Nat. Genet. 2008. V. 40. № 1. P. 23–25. https://doi.org/10.1038/ng.2007.48
Zook J.M., Hansen N.F., Olson N.D. et al. A robust benchmark for detection of germline large deletions and insertions // Nat. Biotechnol. 2020. V. 38. P. 1347–1355. https://doi.org/10.1038/s41587-020-0538-8
Ye J., Coulouris G., Zaretskaya I. et al. Primer-BLAST: A tool to design target-specific primers for polymerase chain reaction // BMC Bioinformatics. 2012. V. 13. № 1. P. 134. https://doi.org/10.1186/1471-2105-13-134
Sequencing analysis viewer [Electronic resource] // Sequencing analysis viewer support. URL: https://support.illumina.com/sequencing/sequencing_software/ sequencing_analysis_viewer_sav.html (accessed: 15.09.2022).
bcl2fastq [Electronic resource] // bcl2fastq. URL: https://emea.support.illumina.com/sequencing/sequencing_software/bcl2fastq-conversion-software/ downloads.html (accessed: 13.05.2022).
FastQC [Electronic resource] // Babraham bioinformatics FastQC a quality control tool for high throughput sequence data. URL: https://www.bioinformatics.babraham.ac.uk/projects/fastqc/ (accessed: 13.05.2022).
Illumina DRAGEN Bio-IT Platform [Electronic resource] // Illumina DRAGEN Bio-IT platform | variant calling & secondary genomic analysis software tool. URL: https://www.illumina.com/products/by-type/informatics-products/dragen-bio-it-platform.html (accessed: 13.05.2022).
Schneider V.A., Graves-Lindsay T., Howe K. et al. Evaluation of GRCh38 and de novo haploid genome assemblies demonstrates the enduring quality of the reference assembly // Genome Res. 2017. V. 27. № 5. P. 849–864. https://doi.org/10.1101/gr.213611.116
Chen X., Schulz-Trieglaff O., Shaw R. et al. Manta: Rapid detection of structural variants and indels for germline and cancer sequencing applications // Bioinformatics. 2016. V. 32. № 8. P. 1220–1222. https://doi.org/10.1093/bioinformatics/btv710
Smoove [Electronic resource] // Brent S. Smoove: structural-variant calling and genotyping with existing tools. URL: https://github.com/brentp/smoove (accessed: 13.07.2022).
Rausch T., Zichner T., Schlattl A. et al. DELLY: structural variant discovery by integrated paired-end and split-read analysis // Bioinformatics. 2012. V. 28. № 18. P. i333–i339. https://doi.org/10.1093/bioinformatics/bts378
NCBI [Electronic resource] // GRCh37 hg19 genome assembly NCBI. URL: https://www.ncbi.nlm.nih.gov/assembly/GCF_000001405.13/ (accessed: 15.09.2022).
Zhao H., Sun Z., Wang J. et al. CrossMap: A versatile tool for coordinate conversion between genome assemblies // Bioinformatics. 2014. V. 30. № 7. P. 1006–1007. https://doi.org/10.1093/bioinformatics/btt730
GDC [Electronic resource] // GDC viewer docs. URL: https://docs.gdc.cancer.gov/Data_Dictionary/viewer/#?view=table-definition-view&id=alignment_cocleaning_workflow (accessed: 13.07.2022).
Li H., Durbin R. Fast and accurate long-read alignment with Burrows–Wheeler transform // Bioinformatics. 2010. V. 26. № 5. P. 589-595. https://doi.org/10.1093/bioinformatics/btp698
Danecek P., Bonfield J.K., Liddle J. et al. Twelve years of samtools and bcftools // GigaScience. 2021. V. 10. № 2. https://doi.org/10.1093/gigascience/giab008
Pedersen B.S., Quinlan A.R. Duphold: scalable, depth-based annotation and curation of high-confidence structural variant calls // GigaScience. 2019. V. 8. № 4. https://doi.org/10.1093/gigascience/giz040
Jeffares D.C., Jolly C., Hoti M. et al. Transient structural variations have strong effects on quantitative traits and reproductive isolation in fission yeast // Nat. Commun. 2017. V. 8. P. 14061. https://doi.org/10.1038/ncomms14061
Witty.er [Electronic resource] // Wan Y., Ho K. Witty.er. URL: https://github.com/Illumina/witty.er (accessed: 13.07.2022).
Unipro UGENE [Electronic resource] // Unipro UGENE: a unified bioinformatics toolkit. Bioinformatics. Oxford academic. URL: https://academic.oup.com/bioinformatics/article/28/8/1166/195474?login=false (accessed: 13.07.2022).
Robinson J.T., Thorvaldsdottir H., Winckler W. et al. Integrative genomics viewer // Nat. Biotechnol. 2011. V. 29. № 1. P. 24–26. https://doi.org/10.1038/nbt.1754
